• Discipline Leisure/Commute

• Material Aluminium

• Front Travel 63mm

• Rear Travel N/A

• Wheel Size 700c

• Warranty Lifetime

Frame - TFS IV - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 50c
Fork - SR Suntour NEX HLO; Coil; 63 mm travel; Lockout; 700x48C max. tyre size
Headset - Merida M2346 Neck
Stem - Merida Comp CC; material: aluminium; 31.8 mm diameter; 17° degree rise; Length: 90mm
Handlebar - Merida Comp CC; material: aluminium; 680mm wide; 15mm rise
Grip - Merida Comp TK
Brake Type - Hydraulic Disc
Front Brake - Shimano MT200; 2 piston with Shimano RT10; 160mm
Rear Brake - Shimano MT200; 2 piston with Shimano RT10; 160mm
Front Tyre - Kenda Ambra K1278; 700x45C; wired; reflective stripe
Rear Tyre - Kenda Ambra K1278; 700x45C; wired; reflective stripe
Wheel Size - 700c
Rim - Merida Comp TK; 20mm inner rim width; 17mm rim depth; material: aluminium
Spokes - Black stainless
Front Hub - Shimano QC300; 100x9mm; 32 Spoke; Centerlock
Rear Hub - Shimano QC300-HM; 135x9mm; 32 Spoke; Centerlock
Speeds - 18
Front Derailleur - Shimano CUES U4000
Rear Derailleur - Shimano CUES U3020; SGS
Shift Levers - Front: Shimano CUES U4000, Rear: Shimano CUES U4000
Chain - KMC xGlide
Cassette - Shimano LG300; 11-36 teeth; 9 speed
Chainset - Shimano CUES U4000; 40-26 tooth chainset; Crank length: (XXS-S) - 170mm, (M-XL) - 175mm
Bottom Bracket - Shimano BB-UN101; 73mm
Pedals - VP VPE-889P
Saddle - Merida Comp TK
Seat Post - Merida Comp CC; material: aluminium; 30.9mm diameter; 5mm layback
