Description
The Crossway is the perfect blend of comfort, enjoyment and all around practicality, suitable for leisure rides or commuting. The core of the Crossway is a comfortable, lightweight aluminium frame with a steep, sloping top tube providing plenty of standover height. For ultimate adaptability, the Crossway range can be equipped with mudguards, racks and kickstands.
SIZING -
- S: 150-164cm
- M: 160-174cm
- L: >165cm
Specifications
-
Discipline Leisure/Commute
-
Material Aluminium
-
Front Travel 63mm
-
Rear Travel N/A
-
Wheel Size 700c
-
Warranty Lifetime
Frame - TFS IV - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 50c
Fork - SR Suntour NEX DS; Coil; 63 mm travel; 700x50C max. tyre size
Headset - Merida M2345
Stem - Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise
Handlebar - Merida CC; material: steel; 620mm wide; 30mm rise
Grip - Merida EC
Brake Type - Mechanical Disc
Front Brake - Shimano BR-M375; mechanical Disc brake with Shimano RT10; 160 mm
Rear Brake - Shimano BR-M375; mechanical Disc brake with Shimano RT10; 160 mm
Front Tyre - Kenda Ambra K1278; 700x45C; wired
Rear Tyre - Kenda Ambra K1278; 700x45C; wired
Wheel Size - 700c
Rim - Merida Comp TK; 17mm inner rim width; material: aluminium
Spokes - Steel UCP
Front Hub - Shimano TX505; 100x9mm; 32 Spoke; Centerlock
Rear Hub - Shimano TX505; 135x9mm; 32 Spoke; Centerlock
Speeds - 21
Front Derailleur - Shimano FD-TY510-3
Rear Derailleur - Shimano RD-M310-7
Shift Levers - Front: Shimano ST-EF500-L, Rear: Shimano ST-EF500-7R
Chain - SunRace CNM 84
Cassette - Shimano CS-HG210-7; 12-32 teeth; 7 speed
Chainset - Shimano TY301; 48-38-28 tooth chainset; material: aluminium; Crank length: (XXS-M) - 170mm, (M/L up) - 175mm
Bottom Bracket - Shimano UN101 LL123
Pedals - VP VPE-891
Saddle - Merida Cross Sport
Seat Post - Merida Comp CC; material: aluminium; 30.9mm diameter; in-line
