  • Merida Big Seven 20 2025

Description

Merida's heartland has always been bombproof aluminium hardtails. Half a century of frame building experience counts for a lot.

All Big Nine and Big Seven models use a sophisticated TFS frame featuring the latest technology:

  • Full internal cable routing for a clean, neat set up,
  • Tapered headtube offering the potential for future upgrades
  • Inboard disc brake mounts protect the brake and maximise stopping power

As much Shimano componentry as possible has been added to complement the modern frame and enhance reliability.

There are a wide range of sizes; Big Nine for taller riders and Big Seven for shorter riders with a healthy overlap between the two.

For riders in the middle, riding style can be taken into account. If you are looking for speed and efficiency choose a Big Nine, if you are looking for agility choose a Big Seven.

Features:

  • Sophisticated aluminium frame
  • Tapered head tube and internal cable routing
  • Hydraulic disc brakes
  • 1 x 8 Shimano drivetrain
  • Lockout fork
  • Shimano hubs & chainset



Specifications

  • Big Seven 20 2025
  • Discipline Trail/XC

  • Material Aluminium

  • Front Travel 100mm

  • Rear Travel Hardtail

  • Wheel Size 27.5"

  • Warranty Lifetime (frame)

FRAME - TFS IV - 6061 aluminium, double butted and technoformed.  Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 27.5" x 2.25"
FORK SR Suntour XCT30 HLO; Coil; 100mm travel; Lockout; Max tyre size 27.5" x 2.25"
GEARS 8
SHIFTERS Shimano ESSA SL-315-8
REAR DERAILLEUR - Shimano ESSA RD-U2000-8; GS
BOTTOM BRACKET - Shimano BB-UN101 73-123
CHAINKMC Z8.3
CHAINSET - Shimano ESSA FC-U2001 32 tooth chainset; Aluminium; Crank length - 170mm (XS/S), 175mm (M/L)
CASSETTE Shimano CS-HG400-8; 11-45 teeth; 8 speed
BRAKE LEVER - Shimano MT200
FRONT BRAKE - Shimano BR-MT200; hydraulic disc brake caliper with Shimano RT10; 160mm rotor
REAR BRAKE - Shimano BR-MT200; hydraulic disc brake caliper with Shimano RT10; 160mm rotor
GRIP Merida EC
HANDLEBAR - Merida CC; aluminium; 690mm wide; 15mm rise
STEM Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Length - 70mm (XS-S), 90mm (M-L)
HEADSET - Merida M2345
PEDALSVP VPE-891
SADDLE Merida Sport comfort
SEATPOST - Merida CC; 30.9mm diameter; 15 mm layback; Aluminium
WHEEL SIZE - 27.5"
RIMS - Merida CC; 17mm inner rim width; aluminium
SPOKES Black steel
FRONT HUB - Shimano TX505; 100 x 9mm; 32 spoke; Centerlock
REAR HUB - Shimano TX505; 135 x 9mm; 32 spoke; Centerlock
FRONT TYRE - Merida K1080; 27.5" x 2.2"; wire bead
REAR TYRE - Merida K1080; 27.5" x 2.2"; wire bead

Merida Big Seven 20 2025

SKU: Q432 / Barcode: 4711256489919

Merida's heartland has always been bombproof aluminium hardtails. Half a century of frame building experience counts for a lot.

All Big Nine and Big Seven models use a sophisticated TFS...

Regular price £700.00
Colour

Size

Out of stock

90 Day Returns -

Description

Merida's heartland has always been bombproof aluminium hardtails. Half a century of frame building experience counts for a lot.

All Big Nine and Big Seven models use a sophisticated TFS frame featuring the latest technology:

  • Full internal cable routing for a clean, neat set up,
  • Tapered headtube offering the potential for future upgrades
  • Inboard disc brake mounts protect the brake and maximise stopping power

As much Shimano componentry as possible has been added to complement the modern frame and enhance reliability.

There are a wide range of sizes; Big Nine for taller riders and Big Seven for shorter riders with a healthy overlap between the two.

For riders in the middle, riding style can be taken into account. If you are looking for speed and efficiency choose a Big Nine, if you are looking for agility choose a Big Seven.

Features:

  • Sophisticated aluminium frame
  • Tapered head tube and internal cable routing
  • Hydraulic disc brakes
  • 1 x 8 Shimano drivetrain
  • Lockout fork
  • Shimano hubs & chainset



Specifications

  • Big Seven 20 2025
  • Discipline Trail/XC

  • Material Aluminium

  • Front Travel 100mm

  • Rear Travel Hardtail

  • Wheel Size 27.5"

  • Warranty Lifetime (frame)

FRAME - TFS IV - 6061 aluminium, double butted and technoformed.  Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 27.5" x 2.25"
FORK SR Suntour XCT30 HLO; Coil; 100mm travel; Lockout; Max tyre size 27.5" x 2.25"
GEARS 8
SHIFTERS Shimano ESSA SL-315-8
REAR DERAILLEUR - Shimano ESSA RD-U2000-8; GS
BOTTOM BRACKET - Shimano BB-UN101 73-123
CHAINKMC Z8.3
CHAINSET - Shimano ESSA FC-U2001 32 tooth chainset; Aluminium; Crank length - 170mm (XS/S), 175mm (M/L)
CASSETTE Shimano CS-HG400-8; 11-45 teeth; 8 speed
BRAKE LEVER - Shimano MT200
FRONT BRAKE - Shimano BR-MT200; hydraulic disc brake caliper with Shimano RT10; 160mm rotor
REAR BRAKE - Shimano BR-MT200; hydraulic disc brake caliper with Shimano RT10; 160mm rotor
GRIP Merida EC
HANDLEBAR - Merida CC; aluminium; 690mm wide; 15mm rise
STEM Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Length - 70mm (XS-S), 90mm (M-L)
HEADSET - Merida M2345
PEDALSVP VPE-891
SADDLE Merida Sport comfort
SEATPOST - Merida CC; 30.9mm diameter; 15 mm layback; Aluminium
WHEEL SIZE - 27.5"
RIMS - Merida CC; 17mm inner rim width; aluminium
SPOKES Black steel
FRONT HUB - Shimano TX505; 100 x 9mm; 32 spoke; Centerlock
REAR HUB - Shimano TX505; 135 x 9mm; 32 spoke; Centerlock
FRONT TYRE - Merida K1080; 27.5" x 2.2"; wire bead
REAR TYRE - Merida K1080; 27.5" x 2.2"; wire bead
