Description
Marin's hardtail trail MTB with the heart of a dirt jump bike, original design in conjunction with Matt Jones, now available with rapid 29" wheel size. The San Quentin is for the aggressive hardtail trail rider looking for a blend between singletrack capabilities and extended air time.
SERIES 2 ALUMINUM FRAME: A light and strong alloy frame designed to be thrashed. Internal cable routing gives a nice clean appearance.
DIRT JUMP INSPIRED FRAME STYLE: Taking cues from the Alcatraz, the San Quentin line up provides all the benefits of the DJ style with massive stand over, slick frame tubes, and a sexy paint job.
MODERN TRAIL GEOMETRY: The slack head tube angle paired with a steep seat tube angle create a ride that will fly uphill with perfect front wheel precision but then descend like it’s on rails. The balanced rider position thanks to the steep seat tube puts your weight between the wheels for impressive climbing and handling on flats, while the slack front end and short rear centre help to pull you through the rough descents and corners with an intuitive feel.
Sizing -
- S: 5'2"- 5'5"
- M: 5'5"- 5'8"
- L: 5'8"- 5'11"
- XL: 5'11"- 6'2"
Specifications
-
Discipline Trail/Dirt-Jump
-
Material Aluminium
-
Front Travel 140mm
-
Rear Travel Hardtail
-
Wheel Size 29"
-
Warranty 5 Years (frame)
FRAME - All New Series 3 6061 Aluminium, Double Butted, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
FRONT SUSPENSION - X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 110x15mm Thru Axle, 44mm Offset
RIM - Marin Aluminium Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible
HUB REAR - Shimano FH-TC500, 148x12, MicroSpline Freehub Body, Centerlock Disc, 32H
HUB FRONT - Shimano HB-TC500, 110x15mm
SPOKES/NIPPLES - 14g Black Stainless Steel
TYRES - Vee Tire Co, Flow Snap, 29x2.6", MPC Compound, Wire Bead
DERAILLEUR REAR - Shimano Deore, 11-Speed, SGS
SHIFT LEVER - Shimano Deore, 11-Speed, SL-5100R
CRANKSET - Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
BOTTOM BRACKET - External Sealed Cartridge Bearing
CHAIN - Shimano CN-LG500
CASSETTE - Shimano CS-5100-11, 11-51T
BRAKES FRONT - Tektro M535 4-Piston Hydraulic, 180mm Rotor
BRAKES REAR - Tektro M535 4-Piston Hydraulic, 180mm Rotor
BRAKE LEVERS - Tektro M535
HANDLEBAR - Marin Mini-Riser, 6061 Double Butted Aluminium, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM - Marin 3D Forged Alloy, 35mm
GRIPS - Marin Grizzly Lock On
HEADSET - FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST - TranzX, YSP18, 1x Remote, All Sizes 170mm Travel, 30.9mm
SADDLE - Marin Speed Concept
PEDALS - Marin Oso OE Flat
Marin San Quentin 2 29 2025
Marin's hardtail trail MTB with the heart of a dirt jump bike, original design in conjunction with Matt Jones, now available with rapid 29" wheel size. The San...
Order within [time] for delivery by [date]
90 Day Returns -
Description
Marin's hardtail trail MTB with the heart of a dirt jump bike, original design in conjunction with Matt Jones, now available with rapid 29" wheel size. The San Quentin is for the aggressive hardtail trail rider looking for a blend between singletrack capabilities and extended air time.
SERIES 2 ALUMINUM FRAME: A light and strong alloy frame designed to be thrashed. Internal cable routing gives a nice clean appearance.
DIRT JUMP INSPIRED FRAME STYLE: Taking cues from the Alcatraz, the San Quentin line up provides all the benefits of the DJ style with massive stand over, slick frame tubes, and a sexy paint job.
MODERN TRAIL GEOMETRY: The slack head tube angle paired with a steep seat tube angle create a ride that will fly uphill with perfect front wheel precision but then descend like it’s on rails. The balanced rider position thanks to the steep seat tube puts your weight between the wheels for impressive climbing and handling on flats, while the slack front end and short rear centre help to pull you through the rough descents and corners with an intuitive feel.
Sizing -
- S: 5'2"- 5'5"
- M: 5'5"- 5'8"
- L: 5'8"- 5'11"
- XL: 5'11"- 6'2"
Specifications
-
Discipline Trail/Dirt-Jump
-
Material Aluminium
-
Front Travel 140mm
-
Rear Travel Hardtail
-
Wheel Size 29"
-
Warranty 5 Years (frame)
FRAME - All New Series 3 6061 Aluminium, Double Butted, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
FRONT SUSPENSION - X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 110x15mm Thru Axle, 44mm Offset
RIM - Marin Aluminium Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible
HUB REAR - Shimano FH-TC500, 148x12, MicroSpline Freehub Body, Centerlock Disc, 32H
HUB FRONT - Shimano HB-TC500, 110x15mm
SPOKES/NIPPLES - 14g Black Stainless Steel
TYRES - Vee Tire Co, Flow Snap, 29x2.6", MPC Compound, Wire Bead
DERAILLEUR REAR - Shimano Deore, 11-Speed, SGS
SHIFT LEVER - Shimano Deore, 11-Speed, SL-5100R
CRANKSET - Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
BOTTOM BRACKET - External Sealed Cartridge Bearing
CHAIN - Shimano CN-LG500
CASSETTE - Shimano CS-5100-11, 11-51T
BRAKES FRONT - Tektro M535 4-Piston Hydraulic, 180mm Rotor
BRAKES REAR - Tektro M535 4-Piston Hydraulic, 180mm Rotor
BRAKE LEVERS - Tektro M535
HANDLEBAR - Marin Mini-Riser, 6061 Double Butted Aluminium, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM - Marin 3D Forged Alloy, 35mm
GRIPS - Marin Grizzly Lock On
HEADSET - FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST - TranzX, YSP18, 1x Remote, All Sizes 170mm Travel, 30.9mm
SADDLE - Marin Speed Concept
PEDALS - Marin Oso OE Flat
