SRAM's Ultimate level Code hydraulic disc brake with carbon lever blade, all the adjustment options you could need and buckets of power.

The full-powered stopper features a new technology to improve your cockpit aesthetic: Stealth. The all-new lever body design brings the hose closer to the bar, allowing for a sleeker, more modern ride. The proven internals remain the same, with SwingLink driving the Code signature feel. For unrivalled ease of customization, Code Ultimate features tool-free Reach and Contact Point Adjust. To top it all off, a carbon blade joins our Lever Pivot Bearing technologies, so feel will remain smooth.

FEATURES

• Stealth body design to complement our AXS cockpit
• Designed for the most heavy-duty braking needs
• Metallic pads come standard for more power and longer wear
• Our most powerful brake, utilizing our SwingLink and Lever Pivot Bearing for a fatigue-free ride

SPECIFICATION

• Brake type: Hydraulic
• Blade material: Carbon
• Contact adjust: Yes
• Rec MMX clamp (not included): MMX clamp, black, titanium
• Pad type (Disc): Steel-backed metal sintered
• Bracket (Disc Brake): Direct mount DIR
• Hose length (mm): 950mm Front, 2000mm Rear
• Reach adjust: Tool-free
• Rec discrete clamp (not included): U-Clamp - Titanium
• Pistons: 4
• Piston material: Phenolic Plastic
• Hose routing angle: Stealth Lever - Adj Caliper
• Caliper body material: Forged Aluminium
• Caliper hardware: Titanium
• Caliper construction: 2-piece
• Hydraulic fluid: DOT 5.1
• Lever pivot: Bearing
• Lever body material: Forged Aluminium
• Rotor type recommended: 1-piece HS2
• Clamp Included (DB): Yes – MMX Clamp
• Caliper Bleed Port: Bleeding Edge
