The Orbea Wild LT H-Team 2027 is the top of the alloy range and proof that Orbea's High Polish Alloy frame is no second-best. It carries the same 170mm travel, the same downhill-developed geometry and the same gravity-ready intent as the carbon bikes, with a premium build bolted on.
FOX 38 Float Factory and FOX Float X2 Factory suspension lead the way, Shimano XT M8200 provides crisp 12-speed shifting and strong four-piston braking, and OQUO MC32TEAM wheels – Orbea's downhill race rims – bring serious durability. It's a hard-hitting alloy enduro e-MTB with a genuinely high-end spec.
Pick full 29in or mullet below; each build uses its own dedicated linkage so the handling stays exactly as intended.
Features
- Orbea High Polish Alloy (Hydro) frame – all of Wild LT's features in aluminium
- FOX 38 Float Factory 170 fork (GRIP X2, Kashima) with FOX Float X2 Factory rear shock
- Shimano XT M8200 12-speed drivetrain
- Shimano XT four-piston hydraulic brakes
- OQUO Mountain Control MC32TEAM POWER wheelset
- 170mm of travel front and rear, with downhill-developed suspension kinematics shared with Orbea's Rallon race bike
- Available in your choice of full 29in or mullet (29in / 27.5in) build – each uses its own dedicated linkage, so the geometry stays consistent
- Flip-chip High/Low geometry adjustment (8mm BB height, 0.5° head angle) plus a reach- and angle-adjustable ZS56 headset standard
- DJI Avinox M2S motor – up to 130Nm of torque (150Nm in Superboost) and 750W of power
- 800Wh battery as standard, with a lighter 600Wh option available for a more agile feel
- DJI Avinox BC100 bar controller
- Low, centred mass for planted, confident handling – complete bike weights start from below 21kg
- Gravity-ready finishing kit with Maxxis Assegai tyres and a FOX 38-class chassis
- Neat touches throughout: multitool integrated into the pivot, replaceable Second Skin frame protection and fully sealed pivot bearings
Specifications
Discipline Enduro e-MTB (full-power)
Material Aluminium (Orbea High Polish Alloy)
Front Travel 170mm
Rear Travel 170mm
Wheel Size 29" or Mullet (29"/27.5") – select your variant
Motor DJI Avinox M2S
Battery 800Wh (600Wh option available)
Frame - Orbea Wild Hydro, 29" wheels, Concentric Boost 12x148
Fork - Fox 38 Float Factory 170, Grip X2, 15x110, Kashima
Shock - Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x65mm
Headset - Acros ZS56
Stem - OC Mountain Control MC21, 0º
Handlebar - OC Mountain Control MC20 Alu SL, Rise 35, Width 800
Brakes - Shimano XT 8220 Hydraulic Disc
Rear Derailleur - Shimano XT M8200 SGS Shadow Plus
Shifters - Shimano XT M8200 I-Spec EV
Cassette - Shimano CS-M8200 10-51t 12-Speed
Chain - Shimano M6100
Chainguide - Orbea eBike chainguide
Crank - e*thirteen Helix Core e*spec
Wheels - Oquo Mountain Control MC32TEAM POWER
Tyres - Maxxis Assegai 2.50" 60TPI Fold 3C MaxxGrip Exo+ TR
Seatpost Remote - Shimano SL-MT500 I-Spec EV
Saddle - Fizik Aidon 208x145mm manganese rail
Battery - DJI Avinox 800Wh
Motor - DJI Avinox M2S
Display - DJI Avinox DP100
Charger - DJI Avinox Charger 4A
Remote - DJI Avinox BC100
Grips - OC Lock On
Computer Mount - OC Computer Mount CM-05, Garmin/Sigma
