The Orbea Terra Race M20iLtd is a race-focused carbon gravel bike for riders chasing the front of the field. Built around the premium OMX carbon frame, it sharpens Terra's adventurous character into a fast, aggressive gravel racer.
The OMX frame is Orbea's lightest, stiffest gravel platform, with a BB386EVO shell, UDH dropout, integrated chain-guide mount and power-meter compatibility. An efficient race position and vibration-damping rear triangle keep you fast and composed across loose, fast terrain, with clearance for up to 45c tyres.
This Terra Race M20iLtd build features a Shimano GRX Di2 RX825 drivetrain, Shimano RX820 Hydraulic Disc braking. Priced at £5,699.
Features
- Orbea Terra Carbon carbon frame — race-focused gravel platform, integrated 1x chain-guide mount
- Shimano GRX Di2 RX825 drivetrain
- Shimano RX820 Hydraulic Disc brakes
- Fork: Orbea Terra Race OMX carbon disc fork, full carbon steerer
- Full carbon Terra Race ICR fork
- BB386EVO shell, UDH dropout and power-meter compatibility
- Clearance for up to 45c tyres
- Fully customisable through Orbea's MyO programme
Specifications
-
DisciplineGravel /
Racing -
FrameCarbon
-
Wheel Size700c
-
Tyre Clearance45c
-
WarrantyLifetime (frame)
Frame - Orbea Terra
Fork - Orbea Terra Race OMX carbon disc fork, full carbon steerer
Headset - FSA 1-1/2" Integrated Aluminium Cup
Handlebar - Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125
Brakes - Shimano RX820 Hydraulic Disc
Front Derailleur - Shimano GRX Di2 RX825
Rear Derailleur - Shimano GRX Di2 RX825
Shifters - Shimano GRX Di2 RX825
Cassette - Shimano Ultegra R8100 11-34t 12-Speed
Chain - Shimano M7100
Crankset - Shimano GRX RX820 31x48t
Front Hub - Orbea Thru Axle 12x100mm M12xP1 Lite
Rear Hub - Orbea Thru Axle 12x142mm M12xP1 Lite
Tyres - Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x40c
Seatpost - OC Performance XP10 Carbon, 27.2mm, Setback 0
Saddle - Selle San Marco Shortfit 2.0 Start Up Off Road
Handlebar Plugs - Orbea Anti-Slippery/Shock Proof
Terra Race M20iLtd 2026
- Gravel
- Carbon frame
Finance available – see options
Order within [time] for delivery by [date]
90 Day Returns
Free product with this bike
Make your choice below
-
Pro builtBuilt and safety-checked by our mechanics before it leaves us
-
Free courier deliveryFree UK delivery on every bike
-
Collect in CanterburyPick up and get set up at our store
-
Talk to a riderChat with our team
The Orbea Terra Race M20iLtd is a race-focused carbon gravel bike for riders chasing the front of the field. Built around the premium OMX carbon frame, it sharpens Terra's adventurous character into a fast, aggressive gravel racer.
The OMX frame is Orbea's lightest, stiffest gravel platform, with a BB386EVO shell, UDH dropout, integrated chain-guide mount and power-meter compatibility. An efficient race position and vibration-damping rear triangle keep you fast and composed across loose, fast terrain, with clearance for up to 45c tyres.
This Terra Race M20iLtd build features a Shimano GRX Di2 RX825 drivetrain, Shimano RX820 Hydraulic Disc braking. Priced at £5,699.
Features
- Orbea Terra Carbon carbon frame — race-focused gravel platform, integrated 1x chain-guide mount
- Shimano GRX Di2 RX825 drivetrain
- Shimano RX820 Hydraulic Disc brakes
- Fork: Orbea Terra Race OMX carbon disc fork, full carbon steerer
- Full carbon Terra Race ICR fork
- BB386EVO shell, UDH dropout and power-meter compatibility
- Clearance for up to 45c tyres
- Fully customisable through Orbea's MyO programme
Specifications
-
DisciplineGravel /
Racing -
FrameCarbon
-
Wheel Size700c
-
Tyre Clearance45c
-
WarrantyLifetime (frame)
Frame - Orbea Terra
Fork - Orbea Terra Race OMX carbon disc fork, full carbon steerer
Headset - FSA 1-1/2" Integrated Aluminium Cup
Handlebar - Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125
Brakes - Shimano RX820 Hydraulic Disc
Front Derailleur - Shimano GRX Di2 RX825
Rear Derailleur - Shimano GRX Di2 RX825
Shifters - Shimano GRX Di2 RX825
Cassette - Shimano Ultegra R8100 11-34t 12-Speed
Chain - Shimano M7100
Crankset - Shimano GRX RX820 31x48t
Front Hub - Orbea Thru Axle 12x100mm M12xP1 Lite
Rear Hub - Orbea Thru Axle 12x142mm M12xP1 Lite
Tyres - Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x40c
Seatpost - OC Performance XP10 Carbon, 27.2mm, Setback 0
Saddle - Selle San Marco Shortfit 2.0 Start Up Off Road
Handlebar Plugs - Orbea Anti-Slippery/Shock Proof
Returns Information
Reviews
This bike hasn't been reviewed yet. Biketart is rated a Top Quality Store by Google, and our team of riders is happy to answer any questions before you buy.
