The Orbea Terra is a gravel race bike, built to be fast and composed whether you're racing the clock, linking up backroads or loading up for an adventure. The frame pairs road-bike efficiency with gravel capability, with clearance for big tyres, a stable-yet-lively geometry and mounts for the gear that long days demand.
Full internal cable routing keeps it clean, the MMS multi-mount system and fender-ready design add versatility, and the frame is ready for 1X or 2X drivetrains. Whether you want a drop-bar racer or a do-anything explorer, Terra adapts to the ride.
The Terra M35Team offers a smartly balanced Terra build that puts your money where it counts. It pairs Shimano GRX RX820 shifting with Shimano RX410 Hydraulic disc brakes on Oquo Road Control RC30TEAM.
Features
- Carbon frame
- Drivetrain: Shimano GRX RX820
- Brakes: Shimano RX410 Hydraulic disc
- Wheels: Oquo Road Control RC30TEAM
- Tyres: Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x45c
- Fast, capable gravel race frame
- Generous tyre clearance for mixed-terrain grip
- Stable, confident gravel geometry
- Full internal cable routing
- MMS multi-mount system and fender-ready design
- 1X and 2X drivetrain compatible
Specifications
Discipline Gravel
Material Carbon
Wheel Size 700c
Warranty Lifetime (frame)
Frame - Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", BB386EVO, powermeter compatible, Thru Axle 12x142mm rear, thread M12xP1, UDH dropout, LOCKR XXL service box, MMS munti mount system, fender ready.
Fork - Orbea Terra Race ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready.
Headset - FSA 1-1/2" Integrated Aluminium Cup
Stem - OC Road Performance RP23, -5º
Handlebar - OC Gravel GR31, Reach 70, Drop 110
Brakes - Shimano RX410 Hydraulic disc
Front Derailleur - Shimano GRX RX820
Rear Derailleur - Shimano GRX RX820
Shifters - Shimano GRX RX610
Cassette - Shimano HG710 11-36t 12-Speed
Chain - Shimano M6100
Crankset - Shimano GRX RX610 30x46t
Wheels - Oquo Road Control RC30TEAM
Rear Hub - Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Front Hub - Orbea Thru Axle 12x100mm M12xP1 Hollow
Tyres - Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x45c
Seatpost - SP 0.2 Carbon, 27.2mm, Setback 20
Saddle - Fizik Terra Argo X7 Aluminium Rail 140mm
Storage - Accesories Containers
Side Bag - Accesories Containers
Handlebar Plugs - OC Components
Terra M35Team 2027
Order within [time] for delivery by [date]
90 Day Returns
