The Orbea Terra M30Team is a carbon gravel bike built for everything from fast gravel rides to long, mixed-surface adventures. Its monocoque OMR carbon frame is light and capable, with a full carbon fork, 12mm thru-axles front and rear and a UDH dropout for wide drivetrain compatibility.
The Terra is designed to be practical as well as fast. The LOCKR XXL service box in the frame keeps your tools and spares tucked away, the MMS multi mount system on the frame and fork lets you carry bottles and bags, and it's mudguard ready for year-round riding.
The build centres on a Shimano GRX 2x12-speed drivetrain with a 46/30t crankset and 11-36t cassette, giving a wide spread of gears for steep climbs and fast descents, with Shimano hydraulic disc brakes for dependable control. Tubeless-ready alloy wheels with 45mm Vittoria Terreno tyres add comfort and grip on loose surfaces, and an OC GR31 gravel bar gives plenty of control in the drops.
Features
- Orbea Terra OMR monocoque carbon frame with full carbon fork
- LOCKR XXL in-frame storage for tools and spares
- MMS multi mount system on frame and fork, mudguard ready
- UDH dropout and power meter compatible BB386EVO bottom bracket
- Shimano GRX 2x12-speed drivetrain with 46/30t crankset and 11-36t cassette
- Shimano hydraulic disc brakes
- Tubeless-ready alloy wheels with Vittoria Terreno T30 700x45c tyres
- OC Gravel GR31 handlebar and SP 0.2 carbon seatpost
Specifications
DisciplineGravel
MaterialCarbon
Wheel Size700c
WarrantyLifetime
Frame - Orbea Terra carbon OMR Disc, monocoque construction, HS 1.5", BB386EVO, power meter compatible, thru-axle 12x142mm rear, thread M12xP1, UDH dropout, LOCKR XXL service box, MMS multi mount system, fender ready
Fork - Orbea Terra Race ICR, full carbon, 1-1/8" - 1.5" tapered head tube compatible, thru-axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready
Headset - FSA 1-1/2" Integrated Aluminium Cup
Stem - OC Road Performance RP23, -5°
Handlebar - OC Gravel GR31, Reach 70, Drop 110
Brakes - Shimano RX410 Hydraulic disc
Front derailleur - Shimano GRX RX820
Rear derailleur - Shimano GRX RX820
Shifter - Shimano GRX RX610
Cassette - Shimano HG710 11-36t 12-speed
Chain - Shimano M6100
Crankset - Shimano GRX RX610 30x46t
Wheels - Alloy, Tubeless, 700c, 21c
Rear hub - Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Front hub - Orbea Thru Axle 12x100mm M12xP1 Hollow
Tyres - Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x45c
Seatpost - SP 0.2 Carbon, 27.2mm, Setback 20
Saddle - Fizik Terra Argo X7 Aluminium Rail 140mm
Storage - Accessories Containers
Side bag - Accessories Containers
Handlebar plugs - OC Components
Terra M30Team 2027
- Gravel
- Carbon frame
Finance available – see options
Order within [time] for delivery by [date]
90 Day Returns
Free product with this bike
Make your choice below
-
Pro builtBuilt and safety-checked by our mechanics before it leaves us
-
Free UK mainland courier deliveryNorthern Ireland: £60
-
Collect in CanterburyPick up and get set up at our store
-
Talk to a riderChat with our team
The Orbea Terra M30Team is a carbon gravel bike built for everything from fast gravel rides to long, mixed-surface adventures. Its monocoque OMR carbon frame is light and capable, with a full carbon fork, 12mm thru-axles front and rear and a UDH dropout for wide drivetrain compatibility.
The Terra is designed to be practical as well as fast. The LOCKR XXL service box in the frame keeps your tools and spares tucked away, the MMS multi mount system on the frame and fork lets you carry bottles and bags, and it's mudguard ready for year-round riding.
The build centres on a Shimano GRX 2x12-speed drivetrain with a 46/30t crankset and 11-36t cassette, giving a wide spread of gears for steep climbs and fast descents, with Shimano hydraulic disc brakes for dependable control. Tubeless-ready alloy wheels with 45mm Vittoria Terreno tyres add comfort and grip on loose surfaces, and an OC GR31 gravel bar gives plenty of control in the drops.
Features
- Orbea Terra OMR monocoque carbon frame with full carbon fork
- LOCKR XXL in-frame storage for tools and spares
- MMS multi mount system on frame and fork, mudguard ready
- UDH dropout and power meter compatible BB386EVO bottom bracket
- Shimano GRX 2x12-speed drivetrain with 46/30t crankset and 11-36t cassette
- Shimano hydraulic disc brakes
- Tubeless-ready alloy wheels with Vittoria Terreno T30 700x45c tyres
- OC Gravel GR31 handlebar and SP 0.2 carbon seatpost
Specifications
DisciplineGravel
MaterialCarbon
Wheel Size700c
WarrantyLifetime
Frame - Orbea Terra carbon OMR Disc, monocoque construction, HS 1.5", BB386EVO, power meter compatible, thru-axle 12x142mm rear, thread M12xP1, UDH dropout, LOCKR XXL service box, MMS multi mount system, fender ready
Fork - Orbea Terra Race ICR, full carbon, 1-1/8" - 1.5" tapered head tube compatible, thru-axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready
Headset - FSA 1-1/2" Integrated Aluminium Cup
Stem - OC Road Performance RP23, -5°
Handlebar - OC Gravel GR31, Reach 70, Drop 110
Brakes - Shimano RX410 Hydraulic disc
Front derailleur - Shimano GRX RX820
Rear derailleur - Shimano GRX RX820
Shifter - Shimano GRX RX610
Cassette - Shimano HG710 11-36t 12-speed
Chain - Shimano M6100
Crankset - Shimano GRX RX610 30x46t
Wheels - Alloy, Tubeless, 700c, 21c
Rear hub - Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Front hub - Orbea Thru Axle 12x100mm M12xP1 Hollow
Tyres - Vittoria Terreno T30 fine loose Gravel Endurance G2.0 700x45c
Seatpost - SP 0.2 Carbon, 27.2mm, Setback 20
Saddle - Fizik Terra Argo X7 Aluminium Rail 140mm
Storage - Accessories Containers
Side bag - Accessories Containers
Handlebar plugs - OC Components
Returns Information
Reviews
This bike hasn't been reviewed yet. Biketart is rated a Top Quality Store by Google, and our team of riders is happy to answer any questions before you buy.
