The Orbea Occam LT is a progressive trail bike, built to be ridden hard when the trail turns steep, fast and loose. It runs 160mm of fork travel and 150mm at the rear on a progressive, coil-friendly suspension platform (around 30% progressivity), so it soaks up big hits while still pedalling efficiently - Occam has always been known for climbing well, and that hasn't changed.

Progressive Trail geometry, the Attitude Adjust flip-chip (High to Low in seconds with the Quick Flip system) and an angle-adjustable headset let you tune it from flowing trail to a near-enduro setup, while a steep seat angle, room for a 230mm dropper, LOCKR storage, a pivot multitool and fully sealed bearings make it a hugely capable, low-fuss machine.

The Occam LT M10 pairs the OMR carbon frame with Fox's top-tier Factory suspension - a Kashima-coated Fox 36 Factory fork and Fox Float X Factory shock - for noticeably more sensitivity and control. Shimano XT 12-speed shifting and XT four-piston brakes handle the controls, while a tough OQUO Mountain Control MC32TEAM wheelset keeps things precise. Premium performance without quite reaching the flagship price.

Features

• Carbon frame
• Fork: Fox 36 Float Factory 160, Grip X, QR15x110, Kashima
• Rear shock: Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm
• Drivetrain: Shimano XT M8200 SGS Shadow Plus
• Brakes: Shimano XT 8220 Hydraulic Disc
• Wheels: Oquo Mountain Control MC32TEAM
• Tyres: Maxxis Assegai 2.50" 60TPI Fold 3C MaxxGrip Exo+ TR
• 160mm fork / 150mm rear travel - progressive, coil-friendly trail suspension (~30% progressivity)
• Attitude Adjust flip-chip (High/Low) plus angle-adjustable headset (±0.75°) to fine-tune the geometry
• 29" wheels, Pure Trail geometry and a steep 78° seat angle for efficient climbing
• Room for up to a 230mm dropper post (Steep 'n' Deep design)
• LOCKR in-frame storage, Fully Loaded Pivot multitool, fully sealed bearings and Second Skin paint protection
