Downhill racing is where it all started for Mondraker and the latest Summum design is the result of many years experience at the top level. Fine tuned, tested and hammered by some of the best riders in the world over the gnarliest of courses our planet has to offer.
The Summum RR MX boasts the best build kit of the Summum line-up. You can therefore expect sublime performance in any condition and over the planets toughest features.
The aluminium Summum frame has geometry identical to the premium carbon version and is covered by the same limited lifetime warranty.
Mondraker ZERO suspension -
ZERO is a virtual pivot suspension system with an exclusive dual link design. The most unique and exclusive feature of ZERO is that the shock floats between the two suspension links and is compressed from both ends. This makes the rear suspension extremely supple on small bumps and big hit capable, really the most acknowledgeable and astounding feature of every Mondraker full suspension bike
SIZING -
- S: 160cm - 170cm
- M: 165cm - 180cm
- L: 175cm - 185cm
- XL: 185cm - 190cm+
Specifications
-
Discipline Downhill
-
Material Aluminium
-
Front Travel 203mm
-
Rear Travel 200mm
-
Wheel Size MX
-
Warranty Lifetime
Frame - Summum MX 6061 Alloy Stealth Evo, Mullet, hydroformed tubing, Updated Zero Suspension System, 200mm travel, Forward Geometry, alloy upper link with shock eyelet bearings, SuperBoost 12x157mm rear axle, UDH, 83mm BSA bottom bracket, MAX. capacity dual row Enduro bearings, HHG internal cable routing, ISCG 05. *Optional Geometry kit
Rear Shock - Fox DHX2 Factory Kashima, 225x75mm. Settings: high and low-speed compression, high and low-speed rebound, spring preload. Super light steel (SLS) spring. Trunnion top mount, 30x8mm bottom bushings
Fork - Fox 40 29 Float GRIP X2 EVOL Factory Kashima, 203mm, air spring, 1-1/8” steerer tube, 20x110mm axle, offset 52mm. Settings: high and low-speed compression, high and low-speed rebound, air preload
Headset - Onoff ZS56/ZS56, 1-1/8", 1-1/8" steerer tube, Sealed bearings, geometry kit cups, external diameter 62mm
Stem - Onoff S9 DH CNC Integrated, 45-50mm adjustable length, 10mm rise, 31.8mm barbore, 7075 alloy, 2x6mm spacer
Handlebar - Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips - Ergon GDH Team black
Seatpost - Onoff S3 DH Alloy, diameter 31.6mm, length 300mm
Saddle - Ergon SM10 DH Black
Front Brake - Sram Maven Ultimate, 18 and 19.5-millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear Brake - Sram Maven Ultimate, 18 and 19.5-millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Brake Lever - Sram Maven Ultimate , SwingLink and lever pivot bearings, tools-free reach adjust
Rims - e*thirteen Grappler Flux carbon, 30mm internal width, tubeless ready, 28 spokes
Spokes - e*thirteen Sapim D-light / Brass
Front Hub - e*thirteen Boost 20x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
Rear Hub - e*thirteen Superboost 12x157mm, Sidekick,12°/15°/18° Adjustable Deadband, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, XD freehub
Front Tire - Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DH casing, 60x2TPI, folding bead
Rear Tire - Maxxis Minion DHR II 27''5x2.5 WT, tubeless ready, 3C Maxx Terra compound, DH protection, 60x2TPI, folding bead
Crankset - Sram X01 DH Carbon, DUB axle, Direct mount chain ring, 165mm CL 56´5
Rings - 36T, aluminum, X-SYNC
Bottom Bracket - Sram DUB BSA, sealed bearings, 83mm
Chain - Sram PC1110 11s, Powerlock
Front Derrailleur - E.13 Vario Compact Upper Slider ,Alloy backplate ,DMB (Direct mount Bashguard) Lower Slider 34-36t, ISCG 05 adjustable upper slider
Rear Derrailleur - Sram X01 DH, 7s, medium cage
Shift Levers - Sram trigger X01 DH 7s, X-actuation 1:1
Cassette - Sram PG 795 10-24T, 7s
Derailleur Hanger - Sram UDH
Others - *Geometry kit included: +- 5mm headset cups, Lower shock mount flip chip, +5mm dropout, -5mm dropout
