Description
Mondraker make some of the best hardtail bikes on the planet. The Prime adds a Bosch Performance CX Cruise motor, the result is one seriously rapid electric mountain bike.
You can count on an engaging riding experience with the Bosch Performance Line CX Smart System motor, equipped with the latest Mini Remote wireless remote control, integrated System Controller, and the Intuvia 100 display. Enjoy a natural pedal-assist with four levels of assistance to cater to your needs.
Bosch Smart System -
The latest Bosch motor is a Performance Line CX Cruise unit that pushes out 85nm, featuring the Bosch Smart System, upgraded software and enhanced firmware modifications. In addition, a new display unit and handlebar mounted control module have been added for easier mode selection and adjustment.
The bikes also feature the Bosch 625Wh battery that allows you to enjoy a long days ride on a single charge.
SIZING -
- S: 160cm - 170cm
- M: 165cm - 180cm
- L: 175cm - 185cm
- XL: 185cm - 190cm+
Specifications
-
Discipline Trail
-
Material Aluminium
-
Front Travel 120mm
-
Rear Travel Hardtail
-
Wheel Size 29"
-
Warranty Lifetime (frame)
Frame - Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
Fork - RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
Stem - Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar - Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Grips - Onoff Beehive, 1lock-on, 135mm
Seatpost - Onoff S3 0-R, diameter 31.6mm, length 400mm
Saddle - MDK ebike black
Front brake - Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake - Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever - Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Rims - Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes - Mavic J-bend double butted, contactless lacing
Front hub - Mavic, Boost 15x110mm, IS 6 bolts
Rear hub - Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire - Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Rear tire - Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Crankset - Race Face Aeffect-R ebike, 160mm
Rings - Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain - Sram SX Eagle, 12s, Powerlock
Rear derailleur - Sram SX Eagle,12s
Shift levers - Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
Cassette - Sram PG-1210, 11-50T, 12s
Derailleur hanger - Sram UDH
Weight - 22,7 kg
Display - Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
Motor - New Bosch Performance Line CX Cruise (25Km/h) SMART SYSTEM (BDU384Y)
Battery - Bosch Powertube 625Wh
Mondraker Prime 2025
Mondraker make some of the best hardtail bikes on the planet. The Prime adds a Bosch Performance CX Cruise motor, the result is one seriously rapid electric mountain bike.
Order within [time] for delivery by [date]
90 Day Returns -
Description
Mondraker make some of the best hardtail bikes on the planet. The Prime adds a Bosch Performance CX Cruise motor, the result is one seriously rapid electric mountain bike.
You can count on an engaging riding experience with the Bosch Performance Line CX Smart System motor, equipped with the latest Mini Remote wireless remote control, integrated System Controller, and the Intuvia 100 display. Enjoy a natural pedal-assist with four levels of assistance to cater to your needs.
Bosch Smart System -
The latest Bosch motor is a Performance Line CX Cruise unit that pushes out 85nm, featuring the Bosch Smart System, upgraded software and enhanced firmware modifications. In addition, a new display unit and handlebar mounted control module have been added for easier mode selection and adjustment.
The bikes also feature the Bosch 625Wh battery that allows you to enjoy a long days ride on a single charge.
SIZING -
- S: 160cm - 170cm
- M: 165cm - 180cm
- L: 175cm - 185cm
- XL: 185cm - 190cm+
Specifications
-
Discipline Trail
-
Material Aluminium
-
Front Travel 120mm
-
Rear Travel Hardtail
-
Wheel Size 29"
-
Warranty Lifetime (frame)
Frame - Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
Fork - RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
Stem - Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar - Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Grips - Onoff Beehive, 1lock-on, 135mm
Seatpost - Onoff S3 0-R, diameter 31.6mm, length 400mm
Saddle - MDK ebike black
Front brake - Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake - Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever - Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Rims - Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes - Mavic J-bend double butted, contactless lacing
Front hub - Mavic, Boost 15x110mm, IS 6 bolts
Rear hub - Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire - Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Rear tire - Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
Crankset - Race Face Aeffect-R ebike, 160mm
Rings - Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain - Sram SX Eagle, 12s, Powerlock
Rear derailleur - Sram SX Eagle,12s
Shift levers - Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
Cassette - Sram PG-1210, 11-50T, 12s
Derailleur hanger - Sram UDH
Weight - 22,7 kg
Display - Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
Motor - New Bosch Performance Line CX Cruise (25Km/h) SMART SYSTEM (BDU384Y)
Battery - Bosch Powertube 625Wh
