The F-Trick 24 is the smaller sibling in Mondraker's kids' full-suspension range, built for riders who have outgrown a 24" hardtail but aren't ready for 26" wheels yet. It uses the same Stealth Evo alloy frame design and Zero Suspension System as the 26, scaled down.
The fork is an X-Fusion Slant RC with 120mm of air-sprung travel, adjustable for lockout, rebound and preload - which means it can be set up properly for a light rider rather than sitting rigid all ride. Out back the X-Fusion O2 PRO R shock is tuned with A-Tune light compression for the same reason.
Shifting is Shimano Deore M6100, 12-speed with a 10-51T cassette - simple, robust and easy to service anywhere. Braking is Shimano MT501 hydraulic discs on 180mm rotors. An X-Fusion Manic dropper post is fitted as standard with 100mm of drop, and the SDG Fly JR saddle and Slater JR pedals are sized for smaller feet and bodies. It weighs 13.8kg.
Features
- F-Trick 6061 alloy Stealth Evo frame, hydroformed tubing
- Zero Suspension System, one-piece bolt-on upper link
- X-Fusion Slant RC fork, 120mm, air sprung with lockout
- Shimano MT501 hydraulic disc brakes with 180mm rotors
- Shimano Deore M6100 12-speed drivetrain, 10-51T cassette
- Short 150mm cranks and a 30T chainring
- X-Fusion Manic LC dropper post, 100mm
- Tubeless-ready MDK-XP1 24" wheels with Maxxis Minion DHF/DHR II tyres
- SDG Fly JR saddle and Slater JR pedals sized for younger riders
- UDH hanger and internal cable routing
- 13.8kg
Specifications
Discipline Trail
Material Alloy
Front Travel 120mm
Rear Travel 130mm
Wheel Size 24"
Weight 13.8kg
Frame - F-Trick 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, 12x148mm rear axle, UDH, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design
Rear Shock - X-Fusion O2 PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock Settings - A-Tune light compression
Fork - X-Fusion Slant RC, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, lock-on, 135mm
Seatpost - X-Fusion Manic LC internal dropper, diameter 31.6mm, 1x remote lever, 100mm
Saddle - SDG Fly JR
Front Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Rear Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Brake Lever - Shimano MT501, Servo Wave, alloy lever
Rims - MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front Hub - DA210FS02, 15x100mm, cup and cone ball bearings, IS 6 bolts
Rear Hub - DA207R, 12x148mm, cup and cone ball bearings, IS 6 bolts, HG freehub
Front Tyre - Maxxis Minion DHF 24x2.4, tubeless ready, 3C MaxxTerra, EXO protection, 60TPI, folding bead
Rear Tyre - Maxxis Minion DHR II 24x2.3, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, direct mount chainring, 150mm
Chainring - 30T, steel
Bottom Bracket - Prowheel PW-MBB73, 73mm
Chain - Shimano Deore M6100, 12s, quick-link
Rear Derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shifter - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Shimano Deore M6100, 10-51T Hyperglide+, 12s
Pedals - SDG Slater JR
Derailleur Hanger - UDH
Weight - 13.8kg
