The F-Play 26 is a full-suspension electric mountain bike built specifically for younger riders, and the point of it is simple: it lets kids keep up on family rides without being wrecked by the climbs. It shares the F-Play alloy Stealth Evo frame and Zero Suspension System with 130mm of rear travel.
Power comes from a Mahle X-30 rear hub motor with a 250Wh internal battery, controlled through the iWoc ONE head unit - a single button on the bar, which is exactly the right level of complexity. A hub motor keeps the weight and bulk down compared to a mid-drive, and at 17.8kg the F-Play is light enough that a child can still handle it off the bike.
The rest is properly specified. An X-Fusion Slant RC fork gives 140mm of adjustable air travel, braking is Shimano MT520 four-piston on 180mm rotors, and shifting is Shimano Deore M6100 12-speed. There's an X-Fusion Manic dropper with 125mm of drop, tubeless-ready wheels, and Maxxis Minion tyres front and rear.
Features
- F-Play 26 6061 alloy Stealth Evo frame, hydroformed tubing
- Mahle X-30 rear hub motor with integrated 250Wh battery
- iWoc ONE single-button head unit
- Zero Suspension System with 130mm rear travel
- X-Fusion Slant RC fork, 140mm, air sprung with lockout
- Shimano MT520 four-piston brakes with 180mm rotors
- Shimano Deore M6100 12-speed drivetrain with 11-51T Sunrace cassette
- X-Fusion Manic LC dropper post, 125mm
- Tubeless-ready MDK-HP1 wheels with Maxxis Minion DHF/DHR II tyres
- SDG Fly JR saddle and Slater JR pedals sized for younger riders
- 17.8kg
Specifications
Discipline Trail
Material Alloy
Front Travel 140mm
Rear Travel 130mm
Wheel Size 26"
Motor Mahle X-30, 250Wh
Frame - F-Play 26 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, integrated internal non-removable battery, tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Rear Shock - X-Fusion O2 PRO R, 165x45mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock Settings - A-Tune light compression
Fork - X-Fusion Slant RC 26, 140mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Motor - Mahle X-30 drive unit
Battery - Mahle iX250Wh
Display - iWoc ONE head unit
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, lock-on, 135mm
Seatpost - X-Fusion Manic LC internal dropper, diameter 31.6mm, 1x remote lever, 125mm
Saddle - SDG Fly JR
Front Brake - Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Rear Brake - Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Brake Lever - Shimano MT501, Servo Wave, alloy lever
Rims - MDK-HP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front Hub - DA210FS02, 15x100mm, cup and cone ball bearings, IS 6 bolts
Rear Hub - Mahle Ebikemotion X-30, HG freehub
Front Tyre - Maxxis Minion DHF 26x2.5, tubeless ready, 3C MaxxTerra, EXO protection, 60TPI, folding bead
Rear Tyre - Maxxis Minion DHR II 26x2.4, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, direct mount chainring, 155mm
Chainring - 30T, steel
Bottom Bracket - Prowheel PW-MBB73, 73mm
Chain - Shimano Deore M6100, 12s, quick-link
Rear Derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shifter - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Sunrace CSMZ600, 11-51T
Pedals - SDG Slater JR
Derailleur Hanger - Mondraker M077
Weight - 17.8kg
F-Play 26 2027
