The F-Play 26 is Mondraker's full-suspension electric mountain bike for older kids and smaller riders, designed to mirror the brand's adult bikes so young riders get the same handling, style and engagement as their parents.
It uses Mondraker's latest Zero Suspension System, the same technology found on the Neat and F-Podium, with 130mm of rear travel paired with a 140mm X-Fusion fork. It reacts quickly to pedal input and gives great feedback from the trail, helping young riders build efficiency, control and confidence on varied terrain.
Power comes from a Mahle X30 rear hub motor with an iX250Wh battery integrated into the frame, assisted up to 25km/h, with an iWoc ONE head unit. The build includes a Shimano Deore 12-speed drivetrain with short 155mm cranks, Shimano four-piston brakes with 180mm rotors, a 125mm dropper post and grippy Maxxis Minion tyres.
Features
- F-Play 26 hydroformed 6061 Stealth Evo alloy frame
- 130mm rear travel via the Zero Suspension System
- Mahle X30 rear hub motor, assisted to 25km/h, with integrated iX250Wh battery
- 140mm X-Fusion Slant RC air fork and X-Fusion 02PRO R shock
- Shimano Deore 12-speed drivetrain with 11-51T cassette and 155mm cranks
- Shimano MT520 four-piston brakes with 180mm rotors
- X-Fusion Manic 125mm internal dropper post
- Maxxis Minion DHF/DHR II 26" EXO tubeless-ready tyres
Sizing
- One size: 145cm - 165cm
Specifications
DisciplineTrail
MaterialAluminium
Front Travel140mm
Rear Travel130mm
Wheel Size26"
WarrantyLifetime (frame)
Frame - F-Play 26 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, integrated internal non-removable battery, tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Motor - Mahle X30 Drive Unit (25km/h)
Battery - Mahle iX250Wh
Display - iWoc ONE Head Unit
Rear shock - X-Fusion 02PRO R, 165x45mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Fork - X-Fusion Slant RC 26, 140mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45°x45°, bottom 52x40x8x45°x45°
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, 1 lock-on, 135mm
Seatpost - X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 125mm
Saddle - SDG Fly JR
Front brake - Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Rear brake - Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Brake lever - Shimano MT501, servo wave, alloy lever
Rims - MDK-HP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front hub - DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub - Mahle-Ebikemotion X30, HG freehub
Front tyre - Maxxis Minion DHF 26x2.5, tubeless ready, 3C MAXX TERRA, EXO protection, 60TPI, folding bead
Rear tyre - Maxxis Minion DHR II 26x2.4, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, Direct mount chainring, 155mm
Chainring - 30T, steel
Bottom bracket - Prowheel PW-MBB73 73mm
Pedals - SDG Slater JR
Chain - Shimano Deore M6100, 12s, Quick-link
Rear derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shift levers - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Sunrace CSMZ600, 11-51T
Derailleur hanger - Mondraker M077
F-Play 26 2026
- Trail / Kids
- 140 / 130mm travel
- 26″ wheels
- Alloy frame
