The F-Play 24 is the smallest full-suspension electric mountain bike Mondraker make. It's aimed at riders who want to come along on proper family rides but can't yet cover the distance or the climbing, and it does that without turning into a heavy, unwieldy thing they can't handle.
Travel is 120mm at both ends - an X-Fusion Slant RC air fork up front and an O2 PRO R shock through the Zero Suspension System at the rear, both tuned light so a smaller rider can actually use the travel. The Mahle X-30 rear hub motor and 250Wh internal battery add assistance without much weight, and the iWoc ONE head unit keeps operation to a single button.
Shimano handles the rest: MT501 hydraulic discs on 180mm rotors and a Deore M6100 12-speed drivetrain with an 11-51T cassette. There's an X-Fusion Manic dropper with 100mm of drop, tubeless-ready 24" wheels and Maxxis Minion tyres. The complete bike weighs 17.2kg.
Features
- F-Play 24 6061 alloy Stealth Evo frame, hydroformed tubing
- Mahle X-30 rear hub motor with integrated 250Wh battery
- iWoc ONE single-button head unit
- Zero Suspension System with 120mm rear travel
- X-Fusion Slant RC fork, 120mm, air sprung with lockout
- Shimano MT501 hydraulic disc brakes with 180mm rotors
- Shimano Deore M6100 12-speed drivetrain with 11-51T Sunrace cassette
- Short 150mm cranks and a 30T chainring
- X-Fusion Manic LC dropper post, 100mm
- Tubeless-ready MDK-HP1 24" wheels with Maxxis Minion DHF/DHR II tyres
- 17.2kg
Specifications
Discipline Trail
Material Alloy
Front Travel 120mm
Rear Travel 120mm
Wheel Size 24"
Motor Mahle X-30, 250Wh
Frame - F-Play 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Rear Shock - X-Fusion O2 PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock Settings - A-Tune light compression
Fork - X-Fusion Slant RC, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Motor - Mahle X-30 drive unit
Battery - Mahle iX250Wh
Display - iWoc ONE head unit
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, lock-on, 135mm
Seatpost - X-Fusion Manic LC internal dropper, diameter 31.6mm, 1x remote lever, 100mm
Saddle - SDG Fly JR
Front Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Rear Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Brake Lever - Shimano MT501, Servo Wave, alloy lever
Rims - MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front Hub - DA210FS02, 15x100mm, cup and cone ball bearings, IS 6 bolts
Rear Hub - Mahle Ebikemotion X-30, HG freehub
Front Tyre - Maxxis Minion DHF 24x2.4, tubeless ready, 3C MaxxTerra, EXO protection, 60TPI, folding bead
Rear Tyre - Maxxis Minion DHR II 24x2.3, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, direct mount chainring, 150mm
Chainring - 30T, steel
Bottom Bracket - Prowheel PW-MBB73, 73mm
Chain - Shimano Deore M6100, 12s, quick-link
Rear Derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shifter - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Sunrace CSMZ600, 11-51T
Pedals - SDG Slater JR
Derailleur Hanger - Mondraker M077
Weight - 17.2kg
F-Play 24 2027
Order within [time] for delivery by [date]
90 Day Returns
The F-Play 24 is the smallest full-suspension electric mountain bike Mondraker make. It's aimed at riders who want to come along on proper family rides but can't yet cover the distance or the climbing, and it does that without turning into a heavy, unwieldy thing they can't handle.
Travel is 120mm at both ends - an X-Fusion Slant RC air fork up front and an O2 PRO R shock through the Zero Suspension System at the rear, both tuned light so a smaller rider can actually use the travel. The Mahle X-30 rear hub motor and 250Wh internal battery add assistance without much weight, and the iWoc ONE head unit keeps operation to a single button.
Shimano handles the rest: MT501 hydraulic discs on 180mm rotors and a Deore M6100 12-speed drivetrain with an 11-51T cassette. There's an X-Fusion Manic dropper with 100mm of drop, tubeless-ready 24" wheels and Maxxis Minion tyres. The complete bike weighs 17.2kg.
Features
- F-Play 24 6061 alloy Stealth Evo frame, hydroformed tubing
- Mahle X-30 rear hub motor with integrated 250Wh battery
- iWoc ONE single-button head unit
- Zero Suspension System with 120mm rear travel
- X-Fusion Slant RC fork, 120mm, air sprung with lockout
- Shimano MT501 hydraulic disc brakes with 180mm rotors
- Shimano Deore M6100 12-speed drivetrain with 11-51T Sunrace cassette
- Short 150mm cranks and a 30T chainring
- X-Fusion Manic LC dropper post, 100mm
- Tubeless-ready MDK-HP1 24" wheels with Maxxis Minion DHF/DHR II tyres
- 17.2kg
Specifications
Discipline Trail
Material Alloy
Front Travel 120mm
Rear Travel 120mm
Wheel Size 24"
Motor Mahle X-30, 250Wh
Frame - F-Play 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Rear Shock - X-Fusion O2 PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock Settings - A-Tune light compression
Fork - X-Fusion Slant RC, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Motor - Mahle X-30 drive unit
Battery - Mahle iX250Wh
Display - iWoc ONE head unit
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, lock-on, 135mm
Seatpost - X-Fusion Manic LC internal dropper, diameter 31.6mm, 1x remote lever, 100mm
Saddle - SDG Fly JR
Front Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Rear Brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Brake Lever - Shimano MT501, Servo Wave, alloy lever
Rims - MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front Hub - DA210FS02, 15x100mm, cup and cone ball bearings, IS 6 bolts
Rear Hub - Mahle Ebikemotion X-30, HG freehub
Front Tyre - Maxxis Minion DHF 24x2.4, tubeless ready, 3C MaxxTerra, EXO protection, 60TPI, folding bead
Rear Tyre - Maxxis Minion DHR II 24x2.3, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, direct mount chainring, 150mm
Chainring - 30T, steel
Bottom Bracket - Prowheel PW-MBB73, 73mm
Chain - Shimano Deore M6100, 12s, quick-link
Rear Derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shifter - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Sunrace CSMZ600, 11-51T
Pedals - SDG Slater JR
Derailleur Hanger - Mondraker M077
Weight - 17.2kg
