The F-Play 24 is Mondraker's full-suspension electric mountain bike for younger riders, mirroring the design and style of the brand's adult bikes so kids get the same look, performance and fun as their parents.
It uses Mondraker's latest Zero Suspension System, shared with the Neat and F-Podium, with 120mm of rear travel paired with a 120mm X-Fusion fork. The updated layout is more sensitive over small bumps, more progressive and lighter, with less unsprung weight and a deeper seatpost insertion, translating rider input into quick, direct acceleration and giving young riders great feedback and control as they develop their skills.
Power comes from a Mahle X30 rear hub motor with an iX250Wh battery integrated into the frame, assisted up to 25km/h, with an iWoc ONE head unit. The build includes a Shimano Deore 12-speed drivetrain with short 150mm cranks, Shimano hydraulic disc brakes with 180mm rotors, a 100mm dropper post and grippy Maxxis Minion tyres.
Features
- F-Play 24 hydroformed 6061 Stealth Evo alloy frame
- 120mm rear travel via the latest Zero Suspension System
- Mahle X30 rear hub motor, assisted to 25km/h, with integrated iX250Wh battery
- 120mm X-Fusion Slant RC air fork and X-Fusion 02PRO R shock
- Shimano Deore 12-speed drivetrain with 11-51T cassette and 150mm cranks
- Shimano MT501 hydraulic disc brakes with 180mm rotors
- X-Fusion Manic 100mm internal dropper post
- Maxxis Minion DHF/DHR II 24" EXO tubeless-ready tyres
Sizing
- One size: 135cm - 155cm
Specifications
DisciplineTrail
MaterialAluminium
Front Travel120mm
Rear Travel120mm
Wheel Size24"
WarrantyLifetime (frame)
Frame - F-Play 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Motor - Mahle X30 Drive Unit (25km/h)
Battery - Mahle iX250Wh
Display - iWoc ONE Head Unit
Rear shock - X-Fusion 02PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Fork - X-Fusion Slant RC 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminium stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset - Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45°x45°, bottom 52x40x8x45°x45°
Stem - Onoff S3 30mm 0°, 6061 forged alloy, 31.8mm barbore
Handlebar - MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9° backsweep, 5° upsweep, 31.8mm barbore
Grips - Onoff Beehive, 1 lock-on, 135mm
Seatpost - X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 100mm
Saddle - SDG Fly JR
Front brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Rear brake - Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
Brake lever - Shimano MT501, servo wave, alloy lever
Rims - MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes - CN round stainless steel
Front hub - DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub - Mahle-Ebikemotion X30, HG freehub
Front tyre - Maxxis Minion DHF 24x2.4, tubeless ready, 3C MAXX TERRA, EXO protection, 60TPI, folding bead
Rear tyre - Maxxis Minion DHR II 24x2.3, tubeless ready, EXO protection, 60TPI, folding bead
Crankset - Prowheel DMJ-CR094S-TT, Direct mount chainring, 150mm
Chainring - 30T, steel
Bottom bracket - Prowheel PW-MBB73 73mm
Pedals - SDG Slater JR
Chain - Shimano Deore M6100, 12s, Quick-link
Rear derailleur - Shimano Deore M6100, SGS, Shadow+, 12s
Shift levers - Shimano Deore M6100, Rapid Fire Plus, 12s
Cassette - Sunrace CSMZ600, 11-51T
Derailleur hanger - Mondraker M077
F-Play 24 2026
- Trail / Kids
- 120 / 120mm travel
- 24″ wheels
- Alloy frame
