e-GRAVEL
Gravel riding has evolved rapidly in recent years, and Mondraker has been at the forefront of this transformation. The gravel category, embraced by riders across disciplines, has brought many back to the roots of cycling: fun, adventure, and the joy of tackling diverse terrain. With a distinctly off-road character, this spirit aligns perfectly with the philosophy behind all Mondraker mountain bikes.
The DUSTY goes all-in on e-Gravel, bypassing the conventional gravel bike path. Equipped with the Mahle X20 rear hub motor, it delivers the power and responsiveness needed, while a 350Wh integrated battery keeps riders going—plus, an optional 185Wh range extender for longer rides.
DUSTY is gravel. It’s e-Gravel. It’s Mondraker. Lightweight, agile, and stable, with the Mahle X20 assisting every pedal stroke, it allows riders to conquer climbs, cover long distances, and maintain high-speed performance across any terrain. And with its unmistakable Mondraker design, it’s clear that this bike is built for adventure, no matter the discipline.
Features:
- Stealth Air Carbon Frame
- 45c Wide Tyres
- Disc Brakes
- 12 Speed
- IX350Wh Battery
Size Guide:
- S: 160cm - 167cm
- M: 167cm - 175cm
- L: 175cm - 185cm
- XL: 185cm - 195cm+
Specifications
-
Discipline Gravel
-
Material Carbon
-
Front Travel Rigid
-
Rear Travel N/A
-
Wheel Size 700c
-
Warranty Lifetime (Frame)
Frame - e-Gravel Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.
Fork - Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Headset - Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.
Stem - Onoff Semi-Integrated, 31.8mm barbore, rise: -7°, length: S size: 60mm, M size: 70mm, L size: 80mm, XL size: 90mm
Handlebar - Onoff S3 GR 16º bar flare. Width sizes S size: 420mm M size: 420mm L size: 440mm XL size: 460mm
Grips - Onoff HEX Bartape
Seatpost - Onoff S3 0-R, diameter 31.6mm, length 400mm
Saddle - Fizik Terra Argo X7 150mm
Front Brake - Sram Apex 1, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear Brake - Sram Apex 1, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake Lever - Sram Apex, contact point adjustment, tooled reach adjust, aluminum levers
Rims - MDK-XG1, 25mm internal width, tubeless ready, 28 spokes
Spokes - CN round stainless steel
Front Hub - Novatec D041, Boost 12x100mm, sealed bearings, IS 6 bolts
Rear Hub - Mahle X20 Drive Unit, MS freehub
Front Tire - Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
Rear Tire - Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
Crankset - Sram Apex 1 Wide, S size: 165mm M size: 170mm L size: 172,5mm XL size: 175mm, CL 47,5
Rings - Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,
Bottom Bracket - Mahle DUB pressfit, sealed bearings, w/ torque sensor
Chain - Sram SX Eagle, 12s, Powerlock
Rear Derrailleur - Sram GX Eagle,12s
Shift Levers - Sram Apex D1 12s, X-Actuation 1:1, single click
Cassette - Sram PG 1210 11-50, 12s
Motor - Mahle X20 Drive Unit
Battery - Mahle X20 IX350Wh
Display - Pulsar One Wireless
Derailleur Hanger - Mondraker M076
Others - Optional external battery: Mahle e185Wh
