Commuting through the week, exploring at the weekend and the occasional multi-day trip - the Silex 300 is aimed at riders who want one bike to cover all of it. The Lite II aluminium frame brings the geometry that defines this platform: a long top tube and head tube with a short stem, which keeps the bike settled on rough ground without making it feel dull on tarmac. Five sets of bottle bosses, rack mounts and internal routing for a dropper post or dynamo give you plenty of scope to set it up your way.
Moving up from the entry model brings hydraulic braking, and that is the change you notice first. Shimano Cues levers and calipers give consistent stopping in the wet, and the Cues 1x9 drivetrain pairs a 42 tooth chainring with an 11-46 SunRace cassette, so there is a low enough bottom gear for loaded climbs. Schwalbe G-One Comp tyres in 700x45C are tubeless ready, as are the Comp SL II rims, and the carbon fork keeps the front end reasonably composed over washboard gravel.
Features
- Lite II 6066 triple butted aluminium frame with internal cable routing
- Silex II CF2 full carbon fork with tapered steerer
- Shimano Cues 1x9 drivetrain, 42 tooth chainring with 11-46 SunRace cassette
- Shimano Cues hydraulic disc brakes
- Schwalbe G-One Comp K-Guard tubeless ready tyres, 700x45C
- Merida Comp SL II tubeless ready rims, 23mm internal width, on Shimano TC500 hubs
- Five sets of bottle bosses plus rack mounting points
- Internal routing for a dropper post and dynamo
- Threaded bottom bracket and 142 x 12mm rear axle
- Clearance for 700 x 45c tyres, 42c with mudguards
Specifications
Discipline Gravel
Material Aluminium
Front Travel Rigid
Wheel Size 700c
Gearing 1x9
Max Tyre 700 x 45c
Frame - Lite II - 6066 triple butted hydroformed and smooth welded aluminium with internal cable routing. Tapered head tube, Inboard disc mounts. Threaded BB, 142 x 12mm axle standard, Max tyre size 700 x 45c (42c with mudguards)
Fork - Silex II CF2; Tapered; carbon; 700x47C max. wheel size
Headset - Acros ICR Merida external neck w/diecast splitring
Stem - Merida Comp CC; aluminium; 31.8mm diameter; -7 degree rise
Handlebar - Merida Comp GR II
Grips - Merida ROAD Expert
Brake Type - Hydraulic Disc
Brake Levers - Shimano Cues
Brakes - Front: Shimano Cues; Hydraulic Disc Rear: Shimano Cues; Hydraulic Disc
Wheels - Rims: Merida Comp SL II; 23mm inner rim width; 24mm deep; aluminium; Tubeless ready (tubeless tape and valves not included) Spokes: Black stainless Front Hub: Shimano TC500; 100x12mm; 28 spoke; Centerlock Rear Hub: Shimano TC500-HM; 12x142mm; 28 spoke; Centerlock
Tyres - Front: Schwalbe G-One Comp K-Guard TLR; 700x45C Rear: Schwalbe G-One Comp K-Guard tubeless ready; 700x45C
Wheel Size - 700c
Speeds - 9
Shifters - Front: Shimano Cues BL-U4030-L Rear: Shimano Cues ST-U4030-R
Rear Derailleur - RD-U4000; 9S
Chainset - FC-U4000-1; 42 teeth; Crank Length: (XXS-L) - 170mm, XL - 175mm
Bottom Bracket - Shimano BBUN 101
Chain - KMC xGlide
Cassette - SunRace U9; CS-U980 9AZ; 11-46 teeth; 9 speed
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seat Post - Merida Comp CC; 27.2mm diameter; in-line; aluminium
