Raced and put through its paces by Team Bahrain Victorious, the Scultura Team is the lightweight, comfort-focused alternative to the Reacto aero bike. The latest Scultura has learned a lot from the Reacto about aerodynamics, but Merida has also worked hard to cut weight even further and make it the most comfortable pure road race bike in the range, with lightning-fast acceleration.
At its heart is the superlight CF5 carbon frame, approximately 822g in size M, with a full carbon tapered fork. The build is pro-level throughout: Shimano Dura-Ace Di2 with a Dura-Ace power meter, Dura-Ace hydraulic disc brakes with Disc Cooler technology, and Vision Metron 45 SL carbon wheels with Continental GP5000S TR 28mm tyres.
A fully integrated Vision Metron 5D carbon cockpit and a carbon seatpost finish off a bike built for racing, big climbs and fast group rides.
Features
- Superlight CF5 carbon frame, approx. 822g in size M
- Full carbon tapered fork with clearance for 30mm tyres
- Shimano Dura-Ace Di2 2x12 groupset
- Shimano Dura-Ace power meter
- Vision Metron 45 SL carbon wheelset
- Continental Grand Prix 5000S TR 28mm tubeless-ready tyres
- Vision Metron 5D integrated carbon cockpit
- Disc Cooler technology
Sizing
- XS: 158cm - 167cm
- S: 163cm - 172cm
- M: 168cm - 177cm
- L: 177cm - 187cm
- XL: 183cm and over
Specifications
DisciplineRoad
MaterialCarbon
Wheel Size700c
WarrantyLifetime
Frame - CF5 V carbon; premium fibres for light weight and performance; race geometry. Internal cable routing, 142x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2" to 1 1/4" head tube. Pressfit 86.5 BB standard. Max tyre size 30c
Fork - Scultura CF5 Disc; material: carbon; 700x30c max tyre size
Headset - FSA ACR; SL bearing
Stem - Vision Metron 5D ACR EVO; material: carbon; length: XXXS-XS 90mm, S 100mm, M-L 110mm, XL 120mm
Handlebar - Vision Metron 5D ACR EVO; material: carbon; XXXS-S 380mm wide, M-L 400mm wide, XL 420mm wide
Bar tape - Prologo One-Touch
Brake type - Hydraulic disc
Brake levers - Shimano Dura-Ace disc
Front brake - Shimano Dura-Ace; hydraulic disc with Shimano CL900; 160mm
Rear brake - Shimano Dura-Ace; hydraulic disc with Shimano CL900; 160mm
Front tyre - Continental Grand Prix 5000S TR; 700x28c; Kevlar bead; tubeless ready
Rear tyre - Continental Grand Prix 5000S TR; 700x28c; Kevlar bead; tubeless ready
Wheel size - 700c
Wheelset - Vision Metron RS 45 SL Clincher TL Disc; 100x12mm front, 142x12mm rear; 23mm inner rim width; 45mm rim depth; Centerlock; material: carbon; tubeless tape ready
Speeds - 24
Front derailleur - Shimano Dura-Ace Di2
Rear derailleur - Shimano Dura-Ace Di2
Shift levers - Front: Shimano Dura-Ace Disc Di2, Rear: Shimano Dura-Ace Disc Di2
Chain - Shimano M9100-12
Cassette - Shimano Dura-Ace R9200; 11-30 teeth; 12 speed
Chainset - Shimano Dura-Ace; 52-36 tooth; power meter; crank length: XXXS 160mm, XXS-XS 165mm, S-M 170mm, L-XL 172.5mm
Bottom bracket - Shimano SM-BB92-41B; Pressfit 86.5
Pedals - Not included
Saddle - Prologo Nago R4 PAS; Nack
Seatpost - Metron RS; 27.2mm diameter; in-line; material: carbon
Scultura Team 2026
- Road
- Alloy frame
Finance available – see options
Order within [time] for delivery by [date]
90 Day Returns
Free product with this bike
Make your choice below
-
Pro builtBuilt and safety-checked by our mechanics before it leaves us
-
Free UK mainland courier deliveryNorthern Ireland: £60
-
Collect in CanterburyPick up and get set up at our store
-
Talk to a riderChat with our team
Raced and put through its paces by Team Bahrain Victorious, the Scultura Team is the lightweight, comfort-focused alternative to the Reacto aero bike. The latest Scultura has learned a lot from the Reacto about aerodynamics, but Merida has also worked hard to cut weight even further and make it the most comfortable pure road race bike in the range, with lightning-fast acceleration.
At its heart is the superlight CF5 carbon frame, approximately 822g in size M, with a full carbon tapered fork. The build is pro-level throughout: Shimano Dura-Ace Di2 with a Dura-Ace power meter, Dura-Ace hydraulic disc brakes with Disc Cooler technology, and Vision Metron 45 SL carbon wheels with Continental GP5000S TR 28mm tyres.
A fully integrated Vision Metron 5D carbon cockpit and a carbon seatpost finish off a bike built for racing, big climbs and fast group rides.
