• Discipline Road

• Material aluminium

• Front Travel Rigid

• Rear Travel N/A

• Wheel Size 700c

• Warranty Lifetime

Frame - Lite : aluminium; BSA BB Standard; 100 x 9mm / 135 x 9mm axle standard; max. tyre size: 700 x 25C
Fork - Scultura Rim CF2; 700x25C max. tyre size
Headset - Merida M2339 Neck
Stem - Merida Comp CC; material: aluminium; 31.8 mm diameter; -7 degree rise; Length: (XXXXS-XS) - 80mm, S - 90mm, (S/M-M/L) - 100mm, (L-XL) - 110mm
Handlebar - Merida Expert SL; material: aluminium; (XXXS-S) - 380mm wide, (M-L) - 400mm wide, XL - 420mm wide
Grip - Merida Road Comp
Brake Type - Calliper
Brake Lever - Shimano CUES
Front Brake - Lee Chi ROAD Dual Pivot
Rear Brake - Lee Chi ROAD Dual Pivot
Front Tyre - Maxxis Pursuer; 700x25C; kevlar bead
Rear Tyre - Maxxis Pursuer; 700x25C; kevlar bead
Wheel Size - 700c
Rim - Merida Comp SL; 17mm inner rim width; 20mm rim depth; material: aluminium; not Tubeless ready
Spokes - Black stainless
Front Hub - Road seal bearing; 100x9mm; 24 Spoke
Rear Hub - Road seal bearing; 130x9mm; 28 Spoke
Speeds - 18
Front Derailleur - Shimano CUES U6030
Rear Derailleur - Shimano CUES; SGS 9S
Shift Levers - Front: Shimano CUES U3030-L, Rear: Shimano CUES U3030-9R
Chain - KMC M700
Cassette - SunRace U98; 11-36 teeth; 9 speed
Chainset - Prowheel; 50-34 tooth chainset; Crank length: (XXXXS-XS) - 165mm, (S-M/L) - 170mm, (L-XL) - 175mm
Bottom Bracket - FSA TH-7420ST, Cartridge Bearing
Pedals - Not included
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seat Post - Merida Comp CC; 27.2mm diameter; in-line; material: aluminium
