If you are stepping up from a hardtail, the One-Twenty 300 is a sensible place to land. The Lite V aluminium frame uses progressive trail geometry and Agilometer sizing, with rattle-free internal cable routing, a long seat post insert depth, Boost axles, a threaded bottom bracket and clearance for a 2.5in tyre.
Suspension comes from X-Fusion at both ends: a Slide 34 RC air fork with 130mm of travel and a lockout, plus an O2 Pro R shock driving the P-FLEX rear end, which keeps pivot maintenance low without giving up much control. The drivetrain is a 1x10 Shimano CUES U6000 with an 11-48 LG400 cassette, braking is by Shimano MT200 hydraulic discs, and Maxxis Rekon 29x2.4 tyres roll quickly across mixed ground. A dropper post is fitted as standard, which matters more than most spec-sheet lines once the trail points down.
Features
- Lite V aluminium frame with progressive trail geometry and Agilometer sizing
- P-FLEX rear suspension, so fewer pivots to service
- X-Fusion Slide 34 RC air fork, 130mm travel, lockout, 44mm offset
- X-Fusion O2 Pro R rear shock
- 1x10 Shimano CUES U6000 drivetrain with Shimano LG400 11-48 cassette
- Shimano MT200 hydraulic disc brakes
- Maxxis Rekon 29x2.4 tyres on tubeless-ready 25mm internal rims
- Dropper post fitted as standard, 150mm or 170mm travel depending on frame size
- Rattle-free internal cable routing, Boost axles, threaded bottom bracket, trail mount and bottle bosses
Specifications
Discipline MTB
Material Alloy
Front Travel 130mm
Wheel Size 29in
Frame - Lite V Aluminium, Progressive trail geometry, agilometer sizing system, rattle free internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, max tyre size - 2.5
Rear Shock - X-Fusion O2 Pro R
Fork - X-Fusion Slide 34 RC; Air; 130mm travel; Tapered; lockout; 44mm fork offset; 29x2.4 max. wheel size
Headset - Acros ICR Merida external neck; Upper and lower IPS sealing
Stem - Merida Comp TR; aluminium; 35mm diameter; 0 degree rise
Handlebar - Merida Comp TR; aluminium; 780mm wide; 20mm rise
Grips - Merida Comp TR
Brake Type - Hydraulic Disc
Brakes - Front: Shimano MT200; 2 piston Rear: Shimano MT200; 2 piston
Wheels - Rims: Merida Comp CC II; 25mm inner rim width; aluminium; tubeless ready Spokes: Black stainless w/black nipples Front Hub: Shimano TC500-B; 110x15mm; 32 spoke; Centerlock Rear Hub: Shimano TC500-HM-B; 148x12mm; 32 spoke; Centerlock
Tyres - Front: Maxxis Rekon; 29x2.4; wire Rear: Maxxis Rekon; 29x2.4; wire
Wheel Size - 29
Speeds - 10
Shifters - Front: Limotec RM06 Rear: Shimano CUES U6000
Rear Derailleur - Shimano CUES U6000; GS
Chainset - Merida Expert TR II; 32 teeth; Crank Length: 170mm for all sizes
Bottom Bracket - Samox BSA 24mm EB2401
Chain - KMC xGlide
Cassette - Shimano LG400; 11-48 teeth; 10 speed
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seat Post - Merida Comp TR IV; 34.9mm diameter; in-line; (XShort-Short) - 150mm seat post travel, (Mid-XLong) 170mm seat post travel
