The One-Sixty FR 800 is all about full-on fun, built for endless hours of sending it rather than sitting in the garage looking pretty. Around a tough aluminium frame, the components are chosen to deliver the best tyres, brakes and suspension possible, rather than lightweight kit that won't last the course.
The One-Sixty FR is designed for the toughest conditions, rated to Category 5 and backed by a 5-year frame warranty. The 800 gets top-level RockShox suspension, with a 180mm Zeb Ultimate fork and a Vivid Coil shock supplied with a size-specific spring rate, while powerful SRAM Maven 4-piston brakes with 220mm and 200mm rotors give huge, controllable stopping power. A flip chip lets you run it as a mullet, with a 29" front and 27.5" rear, or switch to full 29".
Merida's Agilometer sizing takes your riding style into account, so you can choose a longer or shorter reach independently of your height, and the suspension becomes more progressive as you size up. Every size gets a long-travel adjustable dropper, and Wire Port cable routing, a threaded bottom bracket, a DT Swiss F 1900 wheelset, Continental Kryptotal tyres and a Shimano Deore 12-speed drivetrain round out a seriously capable package.
Features
- Tough Lite III aluminium frame, rated to Category 5
- 180mm RockShox Zeb Ultimate fork and RockShox Vivid coil shock
- SRAM Maven 4-piston brakes with 220mm and 200mm rotors
- Flip chip for mixed wheels or full 29"
- DT Swiss F 1900 wheelset with Continental Kryptotal tyres
- Shimano Deore 12-speed drivetrain with 10-51T cassette
- Long-travel, adjustable dropper post on every size
Specifications
DisciplineEnduro/
Freeride MaterialAluminium
Front Travel180mm
Wheel SizeMX (29"/
27.5") Warranty5 years (frame)
Frame - Lite III; aluminium; next generation enduro geometry; internal cable routing; long seatpost insert depth. Boost axle standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. Max tyre size 2.5"
Rear shock - RockShox Vivid Coil; lockout; spring rate: XShort 300lbs, Short 350lbs, Mid 400lbs, Long 450lbs, XLong 500lbs
Fork - RockShox Zeb Ultimate; Air; 180mm travel; 44mm offset; 29x2.6" max tyre size
Headset - Acros ICR Merida external neck; upper and lower IPS sealing
Stem - Merida Expert eTRII; material: aluminium; 35mm diameter; 0 degree rise; length: 40mm
Handlebar - Merida Expert TR II; material: aluminium; 780mm wide; 30mm rise
Grips - Merida Expert TR; recycled material
Brake type - Hydraulic disc
Front brake - SRAM Maven; 4 piston with SRAM CenterLine; 220mm
Rear brake - SRAM Maven; 4 piston with SRAM CenterLine; 200mm
Front tyre - Continental Kryptotal-F; 29x2.4"; Kevlar bead; TR; Enduro casing; Soft compound
Rear tyre - Continental Kryptotal-R; 27.5x2.4"; Kevlar bead; TR; Downhill casing; Soft compound
Wheel size - 29" front, 27.5" rear
Wheelset - DT Swiss F 1900; 110x15mm front, 148x12mm rear; 30mm inner rim width; material: aluminium; tubeless ready (tubeless tape and valves included); front 29", rear 27.5"
Spokes - Double butted black stainless with black nipples
Speeds - 12
Rear derailleur - Shimano Deore M6100; SGS
Shift levers - Front: SRAM dropper lever MMX, Rear: Shimano Deore M6100
Chain - KMC X12
Cassette - Shimano Deore M6100; 10-51 teeth; 12 speed
Chainset - Shimano Deore MT512; 32 tooth; crank length: 165mm
Bottom bracket - Shimano BB-MT501; 24mm
Pedals - Not included
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seatpost - Merida Expert III; 34.9mm diameter; in-line; 25mm travel adjustability; XShort 170mm, Short-Mid 200mm, Long-XLong 230mm seatpost travel
One Sixty FR 800 2026
- Enduro
- 180 / 171mm travel
- Alloy frame
