Some riders want one bike that can take an enduro race, a big mountain descent and a full day of bike park laps without needing a rebuild afterwards. That is the job the One-Sixty 500 is built for. It uses the Lite III aluminium frame with Next Generation enduro geometry and the FAST kinematic suspension design, plus a flip chip that lets you switch between a full 29er and a mullet.
RockShox handles suspension duties, with a Domain Gold R air fork giving 170mm of travel on a 44mm offset, matched to a Super Deluxe shock. The Domain is a deliberately robust chassis rather than a light one, which is the right call on a bike meant for this kind of use.
TRP Slate Evo HD-M7040 four-piston callipers give consistent, powerful braking, and the drivetrain is a 1x12 Shimano Deore M6200 group with a 10-51 cassette, an SGS derailleur and MT520 cranks. Continental Kryptotal tyres in Enduro casing and soft compound are fitted at both ends: a Kryptotal-F 29x2.4 up front, and a Kryptotal-R at the rear in 27.5x2.4 on the smaller frames or 29x2.4 on the larger ones. Wheels use 28mm internal rims on Novatec SL-Team hubs, with a DT Swiss ratchet-compatible rear.
Dropper travel runs from 170mm to 230mm depending on frame size, with 25mm of adjustability built into the post so you can fine-tune the drop rather than live with whatever the size gives you.
Features
- Lite III aluminium frame with Next Generation enduro geometry and Agilometer sizing
- FAST kinematic rear suspension
- Flip chip for a full 29er or mullet wheel setup
- RockShox Domain Gold R air fork, 170mm travel, 44mm offset
- RockShox Super Deluxe rear shock
- TRP Slate Evo HD-M7040 four-piston hydraulic disc brakes
- 1x12 Shimano Deore M6200 drivetrain, 10-51 cassette, SGS derailleur
- Continental Kryptotal-F front and Kryptotal-R rear, Enduro casing, soft compound
- 28mm internal rims on Novatec SL-Team hubs with a DT Swiss ratchet-compatible rear
- Size-specific dropper post, 170mm to 230mm travel with 25mm of adjustability
Specifications
Discipline MTB
Material Alloy
Front Travel 170mm
Wheel Size 29in
Frame - Lite III Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size - 2.5
Rear Shock - Rock Shox Super Deluxe
Fork - Rock Shox Domain Gold R; Air; 170mm travel; Tapered; 44mm fork offset; 29.5x2.8 max. wheel size
Headset - Acros ICR Merida external neck; Upper and lower IPS sealing
Stem - Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise
Handlebar - Merida Comp TR II; aluminium; 780mm wide; 35mm rise
Grips - Merida Comp TR
Brake Type - Hydraulic Disc
Brakes - Front: TRP Slate Evo HD-M7040; 4 piston Rear: TRP Slate Evo HD-M7040; 4 piston
Wheels - Rims: Merida Comp TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); rear 27.5 up to Size M / L & XL rear 29 Spokes: Double Butted Black stainless w/black nipples Front Hub: Novatec SL-Team D041SB-B15; 110x15mm; 32 spoke; 6 bolt Rear Hub: Novatec SL-Team D952RSB; 148x12mm; DT Swiss ratchet compatible; 32 spoke; 6 bolt; MS freehub
Tyres - Front: Continental Kryptotal-F; 29x2.4; fold; TR; Enduro casing; Soft compund Rear: Continental Kryptotal-R; 27.5x2.4 XS/S/M 29x2.4 L/XL; fold; Enduro casing, soft compound
Wheel Size - 29
Speeds - 12
Shifters - Front: Shimano SL-MT500-IL Rear: Shimano Deore M6200
Rear Derailleur - Shimano Deore M6200; SGS
Chainset - Shimano Deore MT520; 32 teeth; Crank Length: 165mm for all sizes
Bottom Bracket - Shimano BB-MT-501; 24mm
Chain - KMC X12
Cassette - Shimano Deore M6200; 10-51 teeth; 12 speed
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seat Post - Merida Expert TR IV; 34.9mm diameter; in-line; 25mm travel adjustability; XShort - 170mm, (Short-Mid) - 200mm, (Long-XLong) - 230mm
