Next Generation enduro geometry in a straightforward aluminium frame is the whole pitch for the One-Forty 400. The Lite III frame carries the same shapes and numbers as the higher-end builds in the family, with internal cable routing, a long seat post insert depth, Boost axles, a threaded bottom bracket and a flip chip so you can set it up as a full 29er or run mixed wheels.
Marzocchi supplies a Z2 air fork with 150mm of travel and a 44mm offset, paired with a Bomber inline shock. It is honest, hard-wearing suspension rather than the lightest on the market, which suits how this bike is likely to be used.
Shifting comes from an 11-speed Shimano CUES U6000 Shadow Plus rear derailleur with a SunRace 10-50 Linkglide cassette, a combination chosen for service life over outright weight, and SRAM DB4 four-piston callipers front and rear do the stopping. Tyres are a Maxxis Minion DHF 29x2.5 up front with a faster Forekaster 29x2.4 at the back, on 28mm internal rims and Shimano Centerlock hubs. Every frame size gets a dropper, from 150mm on the smallest up to 230mm on the largest.
Features
- Lite III aluminium frame with Next Generation enduro geometry and Agilometer sizing
- Flip chip for a full 29er or mullet wheel setup
- Marzocchi Z2 air fork, 150mm travel, 44mm offset
- Marzocchi Bomber inline rear shock
- 11-speed Shimano CUES U6000 Shadow Plus drivetrain with SunRace 10-50 Linkglide cassette
- SRAM DB4 four-piston hydraulic disc brakes front and rear
- Maxxis Minion DHF 29x2.5 front and Forekaster 29x2.4 rear
- Tubeless-ready rims with 28mm internal width on Shimano Centerlock hubs
- Size-specific dropper post, 150mm to 230mm travel
- Internal cable routing, Boost axles, threaded bottom bracket, trail mount and bottle bosses
Specifications
Discipline MTB
Material Alloy
Front Travel 150mm
Wheel Size 29in
Frame - Lite III Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size - 2.5
Rear Shock - Marzocchi Bomber inline
Fork - Marzocchi Z2; Air; 150mm travel; Tapered; 44mm fork offset; 29x2.6 max. wheel size
Headset - Acros ICR Merida external neck; Upper and lower IPS sealing
Stem - Merida Comp TR; aluminium; 35mm diameter; 0 degree rise
Handlebar - Merida Comp TR; aluminium; 780mm wide; 20mm rise
Grips - Merida Comp TR
Brake Type - Hydraulic Disc
Brakes - Front: Sram DB4; 4 piston Rear: Sram DB4; 4 piston
Wheels - Rims: Merida Comp TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); front 29; rear 27.5 Spokes: Black stainless w/black nipples Front Hub: Shimano TC500-B; 110x15mm; 32 spoke; Centerlock Rear Hub: Shimano TC500-HM-B; 148x12mm; 32 spoke; Centerlock
Tyres - Front: Maxxis Minion DHF; 29x2.5; wire Rear: Maxxis Forekaster; 29x2.4; wire
Wheel Size - 29
Speeds - 11
Shifters - Rear: Shimano CUES U6000
Rear Derailleur - Shimano CUES U6000; Shadow Plus
Chainset - Merida Expert TR II; 32 teeth; Crank Length: 170mm for all sizes
Bottom Bracket - Samox BSA 24mm EB2401
Chain - KMC xGlide
Cassette - SunRace 10-50t CS-UX400 EA5; 10-50 teeth; 11 speed; Linkglide
Saddle - Merida Comp SL; 25% recycled material; V-mount; incl. Merida minitool
Seat Post - Merida Expert TR II; 34.9mm diameter; in-line; (XShort-Short) - 150mm seat post travel, Mid - 170mm seat post travel, Long - 200mm seat post travel, XLong - 230mm seat post travel
