The One-Sixty 500 brings Merida's radical, test- and award-winning geometry and suspension design to a tough all-aluminium frame, paired with components that deliver rock-solid performance and excellent value. That makes it a great choice for a first full-suspension enduro bike.
For the money, the spec is very hard to beat. A 170mm RockShox Domain Gold fork and Super Deluxe shock take the rough with the rougher, while Shimano Deore 4-piston brakes with 203mm rotors and a wide-range Deore 12-speed drivetrain are tough and consistent. Tough Continental Kryptotal tyres with soft compound and Enduro casing give plenty of grip and protection.
Smaller sizes (XShort to Mid) run a mixed setup with a 29" front and 27.5" rear, while Long and XLong run full 29" wheels, and a flip chip lets you switch between the two. Merida's Agilometer sizing lets you choose your reach by riding style, and every size gets a long-travel dropper from 150mm to 230mm.
Features
- Full aluminium frame with FAST suspension kinematics and modern enduro geometry
- 170mm RockShox Domain Gold fork and Super Deluxe shock with 160mm travel
- Mixed wheels on XShort-Mid, full 29" on Long-XLong, with flip chip
- Shimano Deore 12-speed drivetrain with 10-51T cassette
- Shimano Deore 4-piston brakes with 203mm rotors
- Continental Kryptotal soft-compound Enduro casing tyres
- Size-specific dropper post from 150mm to 230mm
Sizing
- XShort: 145cm - 165cm
- Short: 155cm - 175cm
- Mid: 165cm - 185cm
- Long: 175cm - 195cm
- XLong: 185cm and over
Merida encourages riders to consider their riding style when choosing a frame size. For example, a 175cm rider could choose a Short frame for agility, Mid for a balanced ride or Long for stability.
Specifications
DisciplineEnduro
MaterialAluminium
Front Travel170mm
Rear Travel160mm
Wheel SizeMX (XS-M), 29" (L-XL)
WarrantyLifetime
Frame - Lite III aluminium; next generation enduro geometry; internal cable routing; long seatpost insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. Max tyre size 2.5"
Rear shock - RockShox Super Deluxe
Fork - RockShox Domain Gold R; Air; 170mm travel; tapered; 44mm fork offset; 29.5x2.8" max tyre size
Headset - Acros ICR Merida external neck; upper and lower IPS sealing
Stem - Merida Expert eTRII; material: aluminium; 35mm diameter; 0 degree rise; length: 40mm
Handlebar - Merida Comp TR II; material: aluminium; 780mm wide; 35mm rise
Grips - Merida Comp TR
Brake type - Hydraulic disc
Front brake - Shimano Deore M6120; 4 piston with Shimano RT30; 203mm
Rear brake - Shimano Deore M6120; 4 piston with Shimano RT30; 203mm
Front tyre - Continental Kryptotal-F; 29x2.4"; Kevlar bead; TR; Enduro casing; Soft compound
Rear tyre - Continental Kryptotal-R; XShort-Mid 27.5x2.4", Long-XLong 29x2.4"; Kevlar bead; Enduro casing; Soft compound
Wheel size - 29" front; 27.5" rear (XShort-Mid), 29" rear (Long-XLong)
Rims - Merida Comp TR II; 28mm inner rim width; material: aluminium; tubeless ready (Stans 30mm tubeless tape installed, valves not included); rear 27.5" up to size M, L and XL rear 29"
Spokes - Double butted black stainless with black nipples
Front hub - Shimano TC500-B; 110x15mm; 32 spoke; Centerlock
Rear hub - Shimano TC500-MS-B; 148x12mm; 32 spoke; Centerlock
Speeds - 12
Rear derailleur - Shimano Deore M6100; SGS
Shift levers - Front: Shimano SL-MT500-IL, Rear: Shimano Deore M6100
Chain - KMC X12
Cassette - Shimano Deore M6100; 10-51 teeth; 12 speed
Chainset - Shimano Deore MT512; 32 tooth; crank length: 165mm
Bottom bracket - Shimano BB-MT501; 24mm
Pedals - Not included
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seatpost - Merida Expert TR II; 34.9mm diameter; in-line; XShort-Short 150mm, Mid 170mm, Long 200mm, XLong 230mm seatpost travel
One-Sixty 500 2026
- Trail / Enduro
- 170 / 160mm travel
- Alloy frame
Finance available – see options
Order within [time] for delivery by [date]
90 Day Returns
-
Pro builtBuilt and safety-checked by our mechanics before it leaves us
-
Free UK mainland courier deliveryNorthern Ireland: £60
-
Collect in CanterburyPick up and get set up at our store
-
Talk to a riderChat with our team
The One-Sixty 500 brings Merida's radical, test- and award-winning geometry and suspension design to a tough all-aluminium frame, paired with components that deliver rock-solid performance and excellent value. That makes it a great choice for a first full-suspension enduro bike.
For the money, the spec is very hard to beat. A 170mm RockShox Domain Gold fork and Super Deluxe shock take the rough with the rougher, while Shimano Deore 4-piston brakes with 203mm rotors and a wide-range Deore 12-speed drivetrain are tough and consistent. Tough Continental Kryptotal tyres with soft compound and Enduro casing give plenty of grip and protection.
Smaller sizes (XShort to Mid) run a mixed setup with a 29" front and 27.5" rear, while Long and XLong run full 29" wheels, and a flip chip lets you switch between the two. Merida's Agilometer sizing lets you choose your reach by riding style, and every size gets a long-travel dropper from 150mm to 230mm.
Features
- Full aluminium frame with FAST suspension kinematics and modern enduro geometry
- 170mm RockShox Domain Gold fork and Super Deluxe shock with 160mm travel
- Mixed wheels on XShort-Mid, full 29" on Long-XLong, with flip chip
- Shimano Deore 12-speed drivetrain with 10-51T cassette
- Shimano Deore 4-piston brakes with 203mm rotors
- Continental Kryptotal soft-compound Enduro casing tyres
- Size-specific dropper post from 150mm to 230mm
Sizing
- XShort: 145cm - 165cm
- Short: 155cm - 175cm
- Mid: 165cm - 185cm
- Long: 175cm - 195cm
- XLong: 185cm and over
Merida encourages riders to consider their riding style when choosing a frame size. For example, a 175cm rider could choose a Short frame for agility, Mid for a balanced ride or Long for stability.
Specifications
DisciplineEnduro
MaterialAluminium
Front Travel170mm
Rear Travel160mm
Wheel SizeMX (XS-M), 29" (L-XL)
WarrantyLifetime
Frame - Lite III aluminium; next generation enduro geometry; internal cable routing; long seatpost insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. Max tyre size 2.5"
Rear shock - RockShox Super Deluxe
Fork - RockShox Domain Gold R; Air; 170mm travel; tapered; 44mm fork offset; 29.5x2.8" max tyre size
Headset - Acros ICR Merida external neck; upper and lower IPS sealing
Stem - Merida Expert eTRII; material: aluminium; 35mm diameter; 0 degree rise; length: 40mm
Handlebar - Merida Comp TR II; material: aluminium; 780mm wide; 35mm rise
Grips - Merida Comp TR
Brake type - Hydraulic disc
Front brake - Shimano Deore M6120; 4 piston with Shimano RT30; 203mm
Rear brake - Shimano Deore M6120; 4 piston with Shimano RT30; 203mm
Front tyre - Continental Kryptotal-F; 29x2.4"; Kevlar bead; TR; Enduro casing; Soft compound
Rear tyre - Continental Kryptotal-R; XShort-Mid 27.5x2.4", Long-XLong 29x2.4"; Kevlar bead; Enduro casing; Soft compound
Wheel size - 29" front; 27.5" rear (XShort-Mid), 29" rear (Long-XLong)
Rims - Merida Comp TR II; 28mm inner rim width; material: aluminium; tubeless ready (Stans 30mm tubeless tape installed, valves not included); rear 27.5" up to size M, L and XL rear 29"
Spokes - Double butted black stainless with black nipples
Front hub - Shimano TC500-B; 110x15mm; 32 spoke; Centerlock
Rear hub - Shimano TC500-MS-B; 148x12mm; 32 spoke; Centerlock
Speeds - 12
Rear derailleur - Shimano Deore M6100; SGS
Shift levers - Front: Shimano SL-MT500-IL, Rear: Shimano Deore M6100
Chain - KMC X12
Cassette - Shimano Deore M6100; 10-51 teeth; 12 speed
Chainset - Shimano Deore MT512; 32 tooth; crank length: 165mm
Bottom bracket - Shimano BB-MT501; 24mm
Pedals - Not included
Saddle - Merida Comp SL; 25% recycled material; V-mount
Seatpost - Merida Expert TR II; 34.9mm diameter; in-line; XShort-Short 150mm, Mid 170mm, Long 200mm, XLong 230mm seatpost travel
