Weight is usually what decides whether a child enjoys riding, so the J.20+ goes without a suspension fork. A budget coil fork adds a couple of kilos to a small bike and does very little in return, so the money goes into a light aluminium fork and a double butted, technoformed 6061 aluminium frame instead. The result is around 9.5kg all in, which is a weight a child can actually lift, turn and pick back up. Maxxis Pace 20 x 2.10 tyres do the cushioning, and the flip-flop stem and spacers let you raise the bar as your child grows. It suits riders of roughly 109-129cm.
The controls are sized for small hands rather than shrunk down from an adult bike. Tektro HD-J3120 hydraulic disc brakes use short reach levers, so there is real stopping power without a child having to stretch for it, and the single Microshift Acolyte trigger shifter has a gear indicator and one click per shift across an 11-34 eight speed cassette. A 32 tooth chainring on 114mm cranks keeps the pedalling circle in proportion to short legs.
Features
- TFS 6061 aluminium frame, double butted and technoformed
- Approximately 9.5kg
- Matts J.20+ rigid aluminium fork
- Suits riders of approximately 109-129cm
- Tektro HD-J3120 hydraulic disc brakes with short reach levers
- Microshift Acolyte 8 speed trigger shifter, short reach with gear indicator
- 32 tooth chainring with 11-34 cassette, 114mm cranks
- Maxxis Pace 20 x 2.10 tyres on Merida JR 20+ aluminium rims
- Flip-flop stem and spacers to raise the bar as the rider grows
- Merida Expert JR 560mm bar with 25mm rise, junior grips and saddle
Specifications
Discipline Kids
Material Aluminium
Front Travel Rigid
Wheel Size 20in
Frame - TFS - 6061 aluminium tubing, double butted and technoformed. BSA BB standard, 9mm QR axle standard. Replaceable dropout. Max tyre size 24 x 2.4
Fork - MATTS J.20+; aluminium; 20x2.4 max. wheel size
Headset - FSA NO.10P Neck15
Stem - Merida Comp CC; aluminium; 31.8mm diameter; 7 degree rise
Handlebar - Merida Expert JR; aluminium; 560mm wide; 25mm rise
Grips - Merida Expert JR
Brake Type - Hydraulic Disc
Brakes - Front: Tektro HD-J3120; hydraulic disc brake; short reach Rear: Tektro HD-J3120; hydraulic disc brake; short reach
Wheels - Rims: Merida JR 20+; aluminium Spokes: Black steel Front Hub: KT-K68F; 100x9mm; 20 spoke Rear Hub: KT-CU8R-8/9/10S; 135x9mm; 24 spoke
Tyres - Front: Maxxis Pace; 20x2.10; wired Rear: Maxxis Pace; 20x2.10; wired
Wheel Size - 20
Speeds - 8
Shifters - Rear: Microshift Acolyte Quick Trigger Pro; SL-M6285-ER; Super short reach; Gear indicator; single click
Rear Derailleur - Microshift Acolyte Speed Super Short Cage; RD-M5180S; Super short cage
Chainset - Prowheel A10PP; 32 teeth; Aluminium; Crank Length: 114mm for all sizes
Bottom Bracket - Squared LL116
Chain - KMC Z8.3
Cassette - Sun Race M55; 11-34 teeth; 8 speed
Pedals - VP-225
Saddle - Merida Comp JR
Seat Post - Merida Comp CC; 27.2mm diameter; in-line; aluminium
