A gravel bike that lets you go further. The eSilex 400 pairs a sophisticated aluminium frame with MAHLE's ebikemotion X30 rear hub motor, so there is quiet, natural-feeling assistance when you want it and a bike that still rides like a bike when you don't.
The X30 drive unit puts out 40Nm through the rear hub, drawing on a 237Wh battery fully integrated into the down tube. System weight stays low and there is almost no drag from the motor when it isn't engaged, which matters on a gravel bike that spends as much time rolling along as it does climbing. Support levels are handled by a single iWoc button on the top tube, and the app lets you tune how the assistance feels as well as looking back over your rides.
Shimano's GRX400 2 x 10 groupset gives a wide, usefully spaced spread of gears for mixed terrain, with hydraulic disc brakes for consistent stopping on loose or wet ground. A MAT carbon fork takes the edge off rough surfaces, and 45mm Schwalbe G-One Comp tyres on tubeless-ready rims give plenty of grip and volume, with clearance for up to 47mm at the front.
The practical details are well thought through. There are mounts for mudguards and a rack, a tidy hidden kickstand mount, and cables run internally through a dedicated headset cap to keep the cockpit clean. That makes it as capable on a commute or a loaded overnighter as it is on a Sunday gravel loop.
Features
- MAHLE ebikemotion X30 rear hub motor with 40Nm of assistance
- 237Wh battery fully integrated into the down tube
- iWoc top tube control button, with app tuning and post-ride analysis
- Low system weight and minimal motor drag when riding unassisted
- Shimano GRX400 2 x 10 gravel drivetrain with hydraulic disc brakes
- MAT carbon fork with clearance for 47mm tyres
- Tubeless-ready Merida Comp SL II wheels on 45mm Schwalbe G-One Comp tyres
- Mudguard, rack and hidden kickstand mounts
- Internal cable routing through a dedicated headset cap
Specifications
Discipline Gravel eBike
Material Aluminium
Motor MAHLE X30, 40Nm
Battery 237Wh
Wheel Size 700c
Frame - eSilex AL-A IV; aluminium; 700Cx45mm max. tyre size; 100x12/135x9 axle standard
Fork - Merida Silex II CF2; Tapered; MAT carbon; 700x47C max. tyre size
Headset - Acros ICR Merida external neck w/diecast splitring
Stem - Merida Team CC III; aluminium; 31.8mm diameter; -6 degree stem angle; incl. MERIDA SMART MOUNT; 80mm
Handlebar - Merida Expert GR II; aluminium; (XXS-XS-S) - 400mm , M - 420mm , (L-XL) - 440mm
Grips - Merida Road Expert
Brake Type - Hydraulic Disc
Brakes - Front: Shimano STRX410; Disc Rear: Shimano STRX410; Disc
Wheels - Rims: Merida Comp SL II; 25mm inner rim width; 24 HRI; aluminium; Tubeless ready (tubeless tape and valves not included) Spokes: Black stainless ; black nipples Front Hub: Shimano TC500; 100x12mm; 28 spoke; Centerlock
Tyres - Front: Schwalbe G-One Comp K-Guard; 700x45C Rear: Schwalbe G-One Comp K-Guard; 700x45C
Speeds - 10
Shifters - Front: Shimano GRX 400; Rear: Shimano GRX 400
Front Derailleur - Shimano GRX400
Rear Derailleur - Shimano GRX400
Chainset - Shimano GRX600; 46-30 teeth, Crank: 165mm
Bottom Bracket - Shimano SM-RS501; 68mm
Chain - KMC e10S
Cassette - Shimano Claris HG50; 11-36 teeth; 10 speed
Pedals - VP VPE-891
Saddle - Merida Comp SL; 28% recycled material; V-mount
Seat Post - Merida Comp CC; 27.2mm diameter; in-line; aluminium
Motor - Mahle ix2 237Wh, Mahle X30 Drive Unit
Battery - 237Wh
eSilex 400 2027
