Description
The geometry of the eBig Nine is a electric bike that follows a simple principle; as sporty as possible, as comfortable as necessary.
The eBig Nine 400 offers the power to do more of what matters, more fun when you're riding off-road, with a powerful 85NM Shimano EP6 drive unit to help you up the hills. More time in the saddle with a 630 Wh battery that'll keep you going for miles. More control, thanks to a SR Suntour suspension fork, chunky tyres and powerful Shimano brakes. More of everything except unnecessary weight, thanks to a high-quality aluminium frame that's also got a lifetime warranty.
SIZING -
- S: 157-173cm
- M: 167-183cm
- L: 177-190cm
- XL: 187-196cm
- XXL: >192cm
Specifications
-
Discipline Trail/Leisure
-
Material Aluminium
-
Front Travel 100mm
-
Rear Travel N/A
-
Wheel Size 29"
-
Warranty Lifetime
Frame - Lite III - Hydroformed 6066 aluminium, integrated battery, internal cable routing, Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Mounts for mudguards and kickstand. Max. tyre size 29"x2.25" with mudguards, 29"x2.35" without
Fork - SR Suntour XCM34-Boost LO-R DS; 100mm travel; Tapered; 44mm fork offset
Headset - Merida-8157
Stem - Merida Expert eTRII; material: aluminium; 35mm diameter; 0 degree rise; GoPro & Supernova mount; length: 50mm
Handlebar - Merida Expert TR II; 760mm wide; 18mm rise
Grip - Merida Comp TK
Brake Type - Hydraulic Disc
Front Brake - Shimano MT-200; 2 piston with Shimano RT30; 180mm
Rear Brake - Shimano MT-200; 2 piston with Shimano RTEM300; 180mm
Front Tyre - Maxxis Ikon; 29x2.2"; kevlar bead
Rear Tyre - Maxxis Ikon; 29x2.2"; kevlar bead
Wheel Size - 29"
Rim - Merida Comp CC II; 25mm inner rim width; material: aluminium
Spokes - Black stainless ; black nipples
Front Hub - Shimano TC500-B; 110x15mm; 32 spoke; Centerlock
Rear Hub - Shimano TC500-HM-B; 148x12mm; 36 spoke; Centerlock
Speeds - 10
Rear Derailleur - Shimano CUES U6000 ; GS
Shift Levers - Rear: Shimano CUES U6000-10
Chain - Shimano LG500
Cassette - Shimano LG300; 11-48 teeth; 10 Speed
Chainset - Shimano CRE70-B; 34 tooth chainset ; Crank: Shimano FC-EM600; 165mm
Bottom Bracket - included
Pedals - VP VPE-537
Saddle - Merida Comp SL; V-mount; incl. Merida minitool
Seat Post - Merida Expert CC; material: aluminium; 34.9mm diameter; in-line
Motor - Shimano EN806; 630Wh, Shimano EP6; 85Nm
Battery Capacity - 630Wh
eBike Display - Shimano SC-EN500A
