Simplicity is the point of the Crossway 20. Instead of a triple chainset it runs a single 40 tooth Shimano Essa ring with an 8-speed 11-45 cassette, so there is one shifter to think about, one cable to maintain and a little less weight to haul about. The 11-45 spread still gives a genuinely low gear for climbing, so nothing is lost on hilly commutes.
Underneath, it is the familiar TFS IV aluminium frame with internal routing, a sloping top tube for easy standover and mounts for a rack, mudguards and a kickstand. Shimano MT200 hydraulic disc brakes take much less hand effort than cable discs, an 80mm SR Suntour XCS28 coil fork smooths out potholes and kerbs, and 700x45C Kenda Ambra tyres keep things comfortable. A 680mm aluminium bar and Comp TK grips and saddle round it off.
Features
- 1x8 Shimano Essa drivetrain: 40 tooth chainset with an 11-45 cassette for simple, wide-range shifting
- Shimano MT200 two-piston hydraulic disc brakes
- TFS IV double butted technoformed 6061 aluminium frame with internal cable routing
- Rack, mudguard and kickstand mounts, with clearance up to 700x50c
- SR Suntour XCS28 coil fork with 80mm of travel
- 700x45C Kenda Ambra tyres on 20mm inner width Merida Comp CC rims with Shimano QC300 Centerlock hubs
- 680mm aluminium bar with 10mm rise, Merida Comp TK grips and saddle
Specifications
Discipline Hybrid/Commute
Material Aluminium
Front Travel 80mm
Wheel Size 700c
Frame - TFS IV - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 50c
Fork - SR Suntour XCS28; Coil; 80mm travel; 29x2.25 max. wheel size
Headset - Merida M2345
Stem - Merida Comp CC; aluminium; 31.8mm diameter; 17 degree rise
Handlebar - Merida Comp CC; aluminium; 680mm wide; 10mm rise
Grips - Merida Comp TK
Brake Type - Hydraulic Disc
Brakes - Front: Shimano MT200; hydraulic 2 piston brake Rear: Shimano MT200; hydraulic brake
Wheels - Rims: Merida Comp CC; 20mm inner rim width; aluminium Spokes: Black steel Front Hub: Shimano QC300; 100x9mm; 32 spoke; Centerlock Rear Hub: Shimano QC300-HM; 135x9mm; 32 spoke; Centerlock
Tyres - Front: Kenda Ambra K1278; 700x45C; wire Rear: Kenda Ambra K1278; 700x45C; wire
Wheel Size - 700c
Speeds - 8
Shifters - Rear: Shimano Essa SL-315-8R
Rear Derailleur - Shimano Essa U2000; GS
Chainset - Shimano Essa; 40 teeth; Crank Length: 170mm for all sizes
Bottom Bracket - Shimano UN101 LL123
Chain - KMC Z8
Cassette - Shimano CS-HG400-8; 11-45 teeth; 8 speed
Pedals - VP VPE-891
Saddle - Merida Comp TK
Seat Post - Merida Comp CC; aluminium; 30.9mm diameter; in-line
