Description
The Big Trail 300 is a fun-packed and capable hardtail trail mountain bike. With its progressive geometry, long-travel 140mm fork, and grippy 2.4" wide 29er trail tyre, it's perfect for exciting trail sessions and challenging all-day rides over rough terrain.
The original Big Trail concept was the result of a few UK dealers discussing the ideal UK trail bike with the Merida R&D chief - simple: 140mm air fork, 29" wheels, 1 x transmission and a dropper post.
Now in its 2nd iteration Big Trail is a fun-packed and hugely capable trail bike. Its progressive geometry combines a steep 76.5° seat angle with a slack 64.0° head angle giving great climbing characteristics and plenty of stability when the terrain gets steep or rough.
Sizing follows the Agilometer principle which means most sizes work for most body sizes so that riding style can be factored in. If you want to go fast, take the longer size, for agility, take a shorter size.
Specifications
-
Discipline Trail
-
Material Aluminium
-
Front Travel 140mm
-
Rear Travel N/A
-
Wheel Size 29"
-
Warranty Lifetime
Frame - TFS - 6061 double butted technoformed aluminium, smooth welding, Boost axle standard, tapered head tube, inboard disc mounts, internal cable routing, BSA BB standard, Max tyre size 29" x 2.5"
Fork - SR Suntour XCR34 2CR; Air; 140 mm travel; Tapered; lockout; 44mm fork offset; 29x2.4" max. tyre size
Headset - Acros ICR Merida External neck; Upper and lower IPS sealing
Stem - Merida Comp TR; material: aluminium; 35 mm diameter; 0 degree rise; Length: 40mm
Handlebar - Merida Comp TR II; material: aluminium; 780mm wide; 35mm rise
Grip - Merida Comp TR
Brake Type - Hydraulic Disc
Front Brake - Shimano MT200; 2 piston with Shimano RT10; 180mm
Rear Brake - Shimano MT200; 2 piston with Shimano RT10; 180mm
Front Tyre - Kenda Regolith; 29x2.4"; wired
Rear Tyre - Kenda Regolith; 29x2.4"; wired
Wheel Size - 29"
Rim - Merida Comp CC II; 25mm inner rim width; material: aluminium; tubeless ready
Spokes - Black stainless
Front Hub - Shimano TC500-B; 110x15mm; 32 Spoke; Centerlock
Rear Hub - Shimano TC500-HM-B; 148x12mm; 32 Spoke; Centerlock
Speeds - 9
Rear Derailleur - Shimano CUES U4000;
Shift Levers - Rear: Shimano CUES U4000
Chain - KMC xGlide
Cassette - SunRace U9; CS-U980 9AZ; 11-46 teeth; 9 speed
Chainset - Shimano CUES UT-400-1; 32 tooth chainset; Crank length: 170mm
Bottom Bracket - Shimano BB-UN101; 73mm
Pedals - Not included
Saddle - Merida Comp SL; V-mount
Seat Post - Merida Comp TR II; 34.9mm diameter; in-line; XShort - 150mm, (Short-XLong) - 170mm seat post travel
