The Big Seven is the 27.5in wheeled counterpart to the Big Nine, built for shorter riders and for anyone who would rather have a bike that flicks between turns than one that carries speed in a straight line. The 15 is the most affordable build in it. Its TFS V frame is double butted, technoformed 6061 aluminium with a tapered head tube, full internal cable routing and chain stay mounted disc brakes, and it uses the longer reach and shorter stem of the current generation rather than the cramped geometry hardtails at this price used to have.
An SR Suntour XCS28 coil fork provides 100mm of travel, and the drivetrain is a Shimano 2x7 with Altus shifters, a Tourney TY300 rear mech and a 12-32 cassette on a Prowheel chainset, which keeps the gear range broad and the servicing simple. Braking is by Shimano BR-M375 mechanical discs. Kenda K1080 tyres in 27.5x2.2 roll easily on trails and towpaths, Merida Comp CC rims with a 20mm internal width sit on Shimano hubs, and mudguard and kickstand mounts make it useful for far more than weekends.
Features
- TFS V double butted and technoformed 6061 aluminium frame
- Tapered head tube, full internal cable routing, chain stay mounted disc brake
- Trail ready geometry: longer reach, shorter stem, slacker head angle
- SR Suntour XCS28 coil fork, 100mm travel
- Shimano 2x7 drivetrain: Altus front mech, Tourney TY300 rear, 12-32 cassette
- Prowheel TM-CY10 36-22 tooth aluminium chainset
- Shimano BR-M375 mechanical disc brakes
- Kenda K1080 27.5x2.2 tyres
- Merida Comp CC rims, 20mm internal width, on Shimano TX505 and QC300-HM Centerlock hubs
- Mudguard and kickstand mounts, BSA threaded bottom bracket, 135 x 9mm rear axle
- Frame clearance for 27.5 x 2.4 tyres; fork rated to 27.5 x 2.25
Specifications
Discipline MTB
Material Aluminium
Front Travel 100mm
Wheel Size 27.5in
Gearing 2x7
Brakes Mechanical disc
Frame - TFS V - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 27.5 x 2.4
Fork - SR Suntour XCS28; Coil; 100mm travel; 27.5x2.25 max. wheel size
Headset - FSA NO.55R/57SC/57B
Stem - Merida Comp CC; aluminium; 31.8mm diameter; 7 degree rise
Handlebar - Merida Comp CC; aluminium; 15mm rise; (XXS-XS) - 700mm; S - 720mm
Grips - Merida EC
Brake Type - Mechanical Disc
Brakes - Front: Shimano BR-M375; mechanical disc brake Rear: Shimano BR-M375; mechanical disc brake
Wheels - Rims: Merida Comp CC; 20mm inner rim width; aluminium Spokes: Black steel Front Hub: Shimano TX505; for SR Suntour 5TA; 100x9mm; 32 spoke; Centerlock Rear Hub: Shimano QC300-HM; 135x9mm; 32 spoke; Centerlock
Tyres - Front: Kenda K1080; 27.5x2.2 Rear: Kenda K1080; 27.5x2.2
Wheel Size - 27.5
Speeds - 14
Shifters - Front: Shimano Altus EF-500-2L Rear: Shimano Altus EF-500-7R
Front Derailleur - Shimano Altus FD-M315
Rear Derailleur - Shimano Tourney TY300
Chainset - Prowheel TM-CY10; 36-22 teeth; Aluminium; Crank Length: 165mm for all sizes
Bottom Bracket - FSA TH-7420ST; 73-127.5mm
Chain - KMC Z7
Cassette - Shimano CS-HG210-7; 12-32 teeth; 7 speed
Pedals - VP VPE-891
Saddle - Merida Sport
Seat Post - Merida CC; aluminium; 30.9mm diameter; 15mm layback
