An air-sprung fork is the dividing line on a bike like this, and the Big Nine 40 is where the range crosses it. X-Fusion's Migo 32 gives 120mm of travel with a lockout, and because it is air rather than coil you can set the spring rate to your own weight instead of accepting whatever the factory fitted. It is the single biggest improvement you can make to how a hardtail rides. Behind it sits the TFS V frame in double butted 6061 aluminium, with a tapered head tube, full internal cable routing and chain stay mounted disc brakes.
Shimano's Cues U4000 1x9 drivetrain runs a 32 tooth chainset against a wide 11-46 SunRace cassette, which keeps steep climbs manageable, and MT200 hydraulic discs give reliable braking in all weathers. Kenda Booster tyres at 29x2.4 make the most of the frame's clearance, and the Comp SL saddle and Comp TR grips are a genuine step up in the parts you actually touch. There is enough frame here to be worth upgrading as your riding progresses.
Features
- TFS V double butted and technoformed 6061 aluminium frame
- Tapered head tube, full internal cable routing, chain stay mounted disc brake
- X-Fusion Migo 32 air fork, 120mm travel with lockout
- Shimano Cues U4000 1x9 drivetrain
- SunRace U9 CS-U980 11-46 nine speed cassette
- Shimano Cues UT400-1 32 tooth aluminium chainset
- Shimano MT200 two piston hydraulic disc brakes
- Kenda Booster 29x2.4 tyres
- Merida Comp CC rims, 20mm internal width, on Shimano QC300 Centerlock hubs
- Merida Comp SL saddle and Comp TR grips
- Mudguard and kickstand mounts, BSA threaded bottom bracket, 135 x 9mm rear axle
Specifications
Discipline MTB
Material Aluminium
Front Travel 120mm
Wheel Size 29in
Gearing 1x9
Brakes Hydraulic disc
Frame - TFS V - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 29 x 2.4
Fork - X-Fusion Migo 32 Air; 120 mm travel; lockout; max. 29x2.4 max. tyre size
Headset - FSA NO.55R/57SC/57B
Stem - Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise
Handlebar - Merida CC; material: aluminium; 15mm rise; S - 720mm wide, (M-L) - 740mm wide, (XL-XXL) - 760mm wide
Grips - Merida Comp TR
Brake Type - Hydraulic Disc
Brakes - Front: Shimano MT200; hydraulic brake with Shimano RT10; 160 mm Rear: Shimano MT200; hydraulic brake with Shimano RT10; 160 mm
Wheels - Rims: Merida Comp CC; 20mm inner rim width; material: aluminium Spokes: Black steel Front Hub: Shimano TX505; 100x9mm; 32 Spoke; Centerlock Rear Hub: Shimano TX505; 135x9mm; 32 Spoke; Centerlock
Tyres - Front: Kenda Booster; 29x2.4 2nd color option: Booster 29x2.4 tanwall Rear: Kenda Booster; 29x2.4 2nd color option: Booster 29x2.4 tanwall
Wheel Size - 29
Speeds - 9
Shifters - Rear: Shimano Cues U4000
Rear Derailleur - Shimano Cues U4000; GS
Chainset - Shimano Cues UT400-1; 32 tooth chainset; material: aluminium ; Crank length: S - 165mm, (M-XXL) - 170mm
Bottom Bracket - Shimano UN101 LL123
Chain - KMC xGlide
Cassette - SunRace U9 CS-U980 9AZ; 11-46 teeth; 9 speed
Pedals - VP VPE 536
Saddle - Merida Comp SL
Seat Post - Merida Comp CC; material: aluminium; 30.9mm diameter; in-line
