Description
Equipped with the latest Shimano XTR Di2 groupset the Merida Big Nine 10K is an utterly modern take on a cross-country race hardtail. The CF5 carbon fibre frame is the lightest Merida produce and is fitted with the best cross-country race Components money can buy; Fox 32 SC Factory fork, the latest wireless Shimano XTR Di2 drivetrain, a FSA NS SIC one-piece carbon cockpit and Reynold Blacklabel 309 carbon wheels. Completely revised frame design with increased fatigue reducing compliance and progressive geometry deliver ruthlessly efficient uphill performance with more descending ability than ever before,
Specifications
Discipline
Material
Front Travel
Rear Travel
Wheel Size 29"
Warranty
Frame - CF5 III - Super lightweight carbon; Boost axle standard, BSA BB standard, Max. tyre size 29" x 2.4"
Fork - Fox 32 SC Factory; Air; 100 mm travel; Tapered; 2 Position Remote lockout; 44mm fork offset; 29x2.4" max. tyre size
Headset - Acros ICR Merida Integrated neck; Upper and lower IPS sealing
Stem - Length: (S-L) - 60mm, (XL-XXL) - 80mm
Handlebar - FSA SIC CF 1-piece cockpit; material: carbon; 760mm wide, -7°; (S-L) - 60mm rise, XL - 80mm rise
Grip - Merida Team CC
Brake Type - Hydraulic Disc
Front Brake - Shimano XTR M9220; 2 piston with Shimano RT-CL900; 180mm
Rear Brake - Shimano XTR M9220; 2 piston with Shimano RT-CL900; 160mm
Front Tyre - Maxxis Rekon Race; 29x2.4" WT; tubeless ready; 3C MaxxTerra EXO
Rear Tyre - Maxxis Rekon Race; 29x2.4" WT; tubeless ready; 3C MaxxTerra EXO
Wheel Size - 29"
Rim - Reynolds Blacklabel 309 XC Pro; 110x15mm; 148x12mm; 30mm inner rim width; Centerlock; Shimano MS 12 Speed; material: carbon; Tubeless ready (tubeless tape and valves included); Lifetime warranty
Spokes - Part of wheelset - Reynolds Blacklabel 309 XC Pro
Front Hub - Part of wheelset - Reynolds Blacklabel 309 XC Pro
Rear Hub - Part of wheelest - Reynolds Blacklabel 309 XC Pro
Speeds - 12
Rear Derailleur - Shimano XTR M9250; wireless; Shadow+ GS
Shift Levers - Rear: Shimano XTR M9250; wireless
Chain - Shimano XTR M9100
Cassette - Shimano XTR M9200; 9-45 teeth; 12 speed
Chainset - Shimano XTR M9200; 30 tooth chainset; Crank length: (S-M) - 170mm, (L-XXL) - 175mm
Bottom Bracket - Shimano SM-BB93; BSA; 24mm axle
Pedals - Not included
Saddle - Prologo Scratch M5 PAS Nack
Seat Post - FSA SL-K; MAT carbon; 30.9mm diameter; in-line
Merida Big Nine 10K 2026
