The Rift Zone 1 27.5 is a great-value trail bike that pairs agile 27.5" wheels with 140mm of travel up front and 130mm at the rear. Its lightweight aluminium frame and Marin's plush MultiTrac suspension make it an excellent, versatile choice for UK trail riding.
MultiTrac is tuned for a balanced ride, soaking up big hits while still giving an efficient pedalling platform. The rocker link gives the shock a progressive leverage ratio, so it's sensitive over small bumps yet feels like a longer-travel bike on big drops and rocks.
The Series 3 aluminium frame has a threaded bottom bracket with ISCG05 tabs and 141mm Boost spacing that can be upgraded to 148x12mm. The build includes X-Fusion suspension, Shimano CUES 11-speed with a wide 11-50T cassette, Tektro hydraulic disc brakes with 180mm rotors, and an X-Fusion Manic dropper post as standard.
The Rift Zone 1 comes with 27.5" wheels in sizes XS, S and M, and with 29" wheels in sizes M, L and XL. You can find the 29" version here.
Features
- Series 3 6061 aluminium frame with MultiTrac suspension
- 140mm front and 130mm rear travel
- Agile 27.5" wheels, ideal for smaller riders
- X-Fusion Sweep RC fork and O2 Pro R shock
- Shimano CUES 11-speed drivetrain with 11-50T cassette
- Tektro HD-M280 hydraulic brakes with 180mm rotors
- X-Fusion Manic dropper post
- Threaded BB with ISCG05 tabs
Sizing
- XS: 5'1" - 5'4"
- S: 5'3" - 5'6"
- M: 5'6" - 5'10"
Specifications
DisciplineTrail
MaterialAluminium
Front Travel140mm
Rear Travel130mm
Wheel Size27.5"
WarrantyLifetime (frame)
Frame - Series 3 6061 aluminium, 130mm travel, MultiTrac suspension platform, 141 Boost spacing (upgradable to 148x12), 73mm threaded BB with ISCG05 tabs
Fork - X-Fusion Sweep Boost RC, 140mm travel, compression and rebound adjust, 44mm offset
Rear shock - X-Fusion O2 Pro R, custom tune, 210x55mm
Rims - Marin aluminium double wall, 29mm inner, pinned joint, tubeless compatible
Front hub - Shimano MT400B, 110x15mm, Centerlock, 32H
Rear hub - Shimano MT200B, 141 QR, Centerlock, standard freehub body
Spokes - 14g black stainless steel
Tyres - Vee Tire Co. Snap WCE 2.35", Top 40 compound, GXE Core, 90 TPI, tubeless compatible
Rear derailleur - Shimano CUES RD-U6000, 11-speed, SGS
Shift lever - Shimano CUES SL-U6000, 11-speed
Crankset - Marin forged alloy, integrated steel 32T narrow-wide chainring, Boost spacing
Chain - Shimano LG500
Cassette - Shimano CUES CS-LG400, 11-speed, 11-50T
Front brake - Tektro HD-M280 hydraulic, 180mm rotor
Rear brake - Tektro HD-M280 hydraulic, 180mm rotor
Brake levers - Tektro HD-M280
Handlebar - Marin Mini-Riser, 6061 double butted aluminium, 780mm width, 28mm rise, 5° up, 9° back
Stem - Marin 3D forged alloy, 35mm
Grips - Marin MTN
Headset - FSA No.57E, sealed cartridge bearings, 1 1/8" x 1 1/2"
Seatpost - X-Fusion Manic dropper, 1x composite remote, 30.9mm, 150mm (XS-S), 170mm (M)
Saddle - Marin Speed Concept
Pedals - Not included
Rift Zone 1 27.5 2027
- Trail
- 140 / 130mm travel
- 27.5″ wheels
- Alloy frame
Finance available – see options
Order within [time] for delivery by [date]
90 Day Returns
-
Pro builtBuilt and safety-checked by our mechanics before it leaves us
-
Free UK mainland courier deliveryNorthern Ireland: £60
-
Collect in CanterburyPick up and get set up at our store
-
Talk to a riderChat with our team
