Description
Downhill racing is where it all started for Mondraker and the latest Summum design is the result of many years experience at the top level. Fine tuned, tested and hammered by some of the best riders in the world over the gnarliest of courses our planet has to offer.
The Summum MX S is fitted with a carefully selected build kit of proven components that will happily take a beating on the trails, maintaining reliability and performing on each drop-in.
The aluminium Summum frame has geometry identical to the premium carbon version and is covered by the same limited lifetime warranty.
Mondraker ZERO suspension -
ZERO is a virtual pivot suspension system with an exclusive dual link design. The most unique and exclusive feature of ZERO is that the shock floats between the two suspension links and is compressed from both ends. This makes the rear suspension extremely supple on small bumps and big hit capable, really the most acknowledgeable and astounding feature of every Mondraker full suspension bike
SIZING -
- S: 160cm - 170cm
- M: 165cm - 180cm
- L: 175cm - 185cm
- XL: 185cm - 190cm+
Specifications
-
Discipline Downhill
-
Material Aluminium
-
Front Travel 200mm
-
Rear Travel 200mm
-
Wheel Size MX
-
Warranty Lifetime
Frame - Summum MX 6061 Alloy Stealth Evo, Mullet, hydroformed tubing, Zero suspension system, 200mm travel, Forward Geometry, alloy upper link with shock eyelet bearings, SuperBoost 12x157mm rear axle, 83mm BSA bottom bracket, MAX. capacity dual row Enduro bearings, HHG internal cable routing, ISCG 05. *Optional Geometry kit
Rear Shock - Rock Shox Vivid Coil Select R, 225x70mm. Rebound adjustable, HBO adjust and spring preload. Trunnion top mount, 30x8mm bottom bushings
Fork - Rockshox Boxxer Select RC 29, 200mm, DebonAir+, 1-1/8” steerer tube, Boost 20x110mm axle, offset 52mm. Settings: low-speed compression, rebound, air preload
Headset - Onoff ZS56/ZS56, 1-1/8", 1-1/8" steerer tube, 42x30x7x45ºx45º ACB sealed bearings, geometry kit cups, external diameter 62mm
Stem - Onoff S9 DH CNC Integrated, 45-50mm adjustable length, 10mm rise, 31.8mm barbore, 7075 alloy, 2x6mm spacer
Handlebar - Onoff S6 1.0 7075 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Grips - Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost - Onoff S3 DH Alloy, diameter 31.6mm, length 300mm
Saddle - Ergon SM10 DH Black
Front Brake - Sram DB8, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear Brake - Sram DB8, oversized 4-piston caliper, Centerline 203mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Brake Lever - Sram DB8, tool reach adjust, lever pivot bushings
Rims - Mavic Deemax BikePark 29, 30mm internal width, 32 holes
Spokes - Mavic 32 steel flat spokes
Front Hub - Mavic Boost 20x110mm, IS 6 bolts
Rear Hub - Mavic 12x157mm, ID360 freewheel, sealed bearings, IS 6 bolts, HG freehub
Front Tire - Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
Rear Tire - Maxxis DHR II 27''5x2.5 WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
Crankset - Sram Truvativ Descendant DH, DUB axle, Direct mount chain ring, 165mm CL 56´5
Rings - 34T, steel, X-SYNC
Bottom Bracket - Sram DUB BSA, sealed bearings, 83mm
Chain - Sram PC1110 11s, Powerlock
Front Derrailleur - E.13 Vario Compact Upper Slider ,Alloy backplate ,DMB (Direct mount Bashguard) Lower Slider 34-36t, ISCG 05 adjustable upper slider
Rear Derrailleur - Sram GX DH, 7s, medium cage
Shift Levers - Sram trigger GX DH 7s, X-actuation 1:1
Cassette - Sram PG 720 11-25T, 7s
Derailleur Hanger - Mondraker M068
Others - *Optional geometry kit: +-1º / +-2º headset cups
