The 2027 Marin TAM XR is the flagship of the TAM range—taking everything that makes this platform so good and turning it all the way up. Lighter, sharper and loaded with premium kit, it’s built for riders who want maximum performance from a short-travel bike without losing real-world capability.
This is down-country at full tilt.
The TAM XR is Marin’s top-tier build, combining a lightweight Series 4 alloy frame with elite-level components and cutting-edge tech. It’s designed to deliver race-ready efficiency with trail bike confidence, making it one of the most complete bikes in this category.
With 120mm rear / 130mm front travel and aggressive geometry, it keeps things fast and efficient while staying composed when the trail gets rough
Key Features -
- Series 4 aluminium frame – Marin’s lightest full-suspension chassis to date
- 120mm rear / 130mm front travel (IsoTrac suspension) – efficient climbing, capable descending
- Fox 34 SL Performance Elite fork + Float SL shock – top-tier suspension performance
- Shimano Deore Di2 wireless drivetrain (12-speed) – precise, modern electronic shifting
- SRAM 4-piston brakes – powerful, consistent stopping control
- 29” wheels with Maxxis Rekon Race tyres – fast rolling with surprising grip
- PNW Loam dropper post – premium finishing kit for proper trail riding
Sizing -
- Small (S): 158 – 165 cm
- Medium (M): 165 – 173 cm
- Large (L): 173 – 180 cm
- X-Large (XL): 180 – 188 cm
Specifications
-
Discipline Trail / XC
-
Material Aluminium
-
Front Travel 130mm
-
Rear Travel 120mm
-
Wheel Size 29"
-
Warranty Lifetime (frame)
Frame - All new Series 4 Aluminium, 29" Wheels, 120mm IsoTrac Suspension Platform, Full Internal Cable Routing, Chainstay Mounted 160MM DM, 148x12mm Boost Thru-Axle, 73mm BB Shell, ISCG 05 Tabs
Rear Shock - Fox Float SL Performance Elite, 3-Pos Compresion Adjust, EVOL LV Air Spring, 190x45mm, 30x8m Hardware, 0.6 VC, CL+ RF CMF Tune
Fork - Fox 34SL Performance Elite, 130mm Travel, Grip X Damper, Kabolt SL Axle 110x15mm, Tapered Steerer Tube, 44mm Offset
Rear Derailleur - Shimano Deore Di2, 12-Speed
Shifter - Shimano Deore Di2, 12-Speed
Cassette - Shimano Deore, 12-Speed, 11-51T, 12-Speed
Chain - KMC X-12 Silver and Black
Tyres - Maxxis Rekon Race, 29x2.35", Folding Bead, Tubeless Ready
Hubs - WTB, 28H
Rims - WTB KOM Light i30, 28H
Brakes - SRAM Motiv Silver, 4-Piston Hydraulic Disc, HSC 180mm Rotor
Handlebar, Stem and Saddle - Marin
Post - PNW Loam Dropper Post Gen 2+, Range Lever MMX Clamp, Adjustable Travel, 30.9mm Diameter, S = 150MM / M = 170MM / L-XL = 200MM
Grips - Marin Grizzly Lock-On
